Section Three: Simplex 4010 NION Explorer
3.1 Simplex Explorer Overview
The Simplex 4010 NION Explorer is a plug-in application that provides the ability to view panel information and
NION configurations from a UniNet™ 2000 workstation. The Simplex Explorer operates much like Windows
Explorer. It displays NION and Panel information in expandable menus the same way Windows Explorer displays
the file system in expandable file folders.
3.2 Simplex 4010 Explorer Operation
3.2.1 Registering and Opening the Simplex Explorer
To open the Simplex Explorer application from the UniNet™ 2000 workstation it must first be properly registered
with the appropriate NION type. This is done through the workstation by a two-step process.
•
From the UniNet™ Workstation (UWS), go to the Workstation Configuration menu and select Nion
Applications. Locate the NION Type drop-down box. Scroll through the drop-down list and select the
Simplex 4010 NION. Click the CHANGE button on the form. This will cause a dialogue box to be
displayed with the names of all available configuration files. Select SX4010.cfg and then click the OPEN
button. Finally, click DONE to end the registration process.
•
From the UWS, go to the Tools menu and click on Node Control Selection. Take control of the node by
clicking on the node number for the Simplex 4010 NION, then click on the button labeled Activate
Control For This Node. Click on the DONE button to end the process.
Once the Simplex plug-in is registered it is opened by right-clicking on any device associated with a Simplex 4010
NION and selecting Simplex 4010 Explorer from the pop-up menu.
3.2.2 The Simplex 4010 Explorer Main Form
Like Windows Explorer, the Simplex Explorer screen is displayed as two panes. The left pane displays the expand-
able list of panel and NION properties, while the right pane shows detailed information about the particular item
highlighted. Navigate through the devices associated with a Simplex 4010 Panel simply by expanding and
collapsing the menu in the left pane. Highlighting a device in the menu will display its properties and value in the
right pane.
