UniNet™ 2000
Simplex 4010 NION
Installation and Operation Manual
Document 51998
A1
03/26/03
Rev
51998:A1
ECN 02-298
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UniNet 2000 Simplex 4010 NION and is the answer not in the manual?

Questions and answers

Related Manuals for Notifier UniNet 2000 Simplex 4010 NION

Summary of Contents for Notifier UniNet 2000 Simplex 4010 NION

  • Page 1 UniNet™ 2000 Simplex 4010 NION Installation and Operation Manual Document 51998 03/26/03 51998:A1 ECN 02-298 Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
  • Page 2 This page intentionally left blank. Simplex 4010 NION Installation/Operation Manual Version 2 Document 51998 Rev. A1 03/26/03 Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
  • Page 3 Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! Heat detectors do not sense particles of combustion and alarm An automatic fire alarm system–typically made up of smoke detectors, heat detectors, manual pull stations, audible warning only when heat on their sensors increases at a predetermined devices, and a fire alarm control with remote notification capabil-...
  • Page 4 Acclimate Plus™, HARSH™, NOTI•FIRE•NET™, ONYX™, and VeriFire™ are trademarks, and FlashScan® and VIEW® are registered trademarks of NOTIFIER. NION™ and UniNet™ are trademarks of NIS. NIS™ and Notifier Integrated Systems™ are trademarks and NOTIFIER® is a registered trademark of Fire•Lite Alarms, Inc.

  • Page 5: Table Of Contents

    Contents Foreword ...............7 Introduction................7 Section One: Simplex 4010 NION Hardware ..........9 1.1: General Description ........................ 9 1.2: Hardware Description ......................9 Figure 1-1: NION-NPB Layout ......................10 1.3: SMX Network Connection ....................11 Figure 1-2: SIMPLEX 4010 NION TB5 Power Connection ..............11 1.4: SMX Network Transceivers ....................
  • Page 6 Simplex 4010 NION Installation/Operation Manual Version 2 Document 51998 Rev. A1 03/26/03 Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...

  • Page 7: Foreword

    Foreword The contents of this manual are important and must be kept in close proximity of the UniNet™ Facilities Monitoring System. If building ownership is changed, this manual and all other testing and maintenance information must also be passed to the current owner of the facility. A copy of this manual was shipped with the equipment and is also available from the manufacturer.
  • Page 8 This page intentionally left blank. Simplex 4010 NION Installation/Operation Manual Version 2 Document 51998 Rev. A1 03/26/03 Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...

  • Page 9: Section One: Simplex 4010 Nion Hardware

    Section One: Simplex 4010 NION Hardware 1.1: General Description The Simplex 4010 NION interfaces to a Simplex 4010 FACP to provide monitoring of the Simplex 4010 to a UniNet™ 2000 network. The NION is based on the NION-NPB motherboard hardware and communicates with the FACP via a 4-wire EIA-232 connection.
  • Page 10 R72 Cut T R72 Cut T R72 Cut T R72 Cut T R72 Cut To Disable Ground o Disable Ground o Disable Ground o Disable Ground o Disable Ground Fault Detection Fault Detection Fault Detection Fault Detection Fault Detection P P P P P ower Input (TB5) ower Input (TB5) ower Input (TB5) ower Input (TB5)

  • Page 11: Smx Network Connection

    NOTES: It is recommended that the installer conform to local code requirements when installing all wiring . All power connections must be non-resettable. Refer to the current Notifier catalog for specific part numbers and ordering information for each NION. Always remove power from the NION before making any changes to switch settings and removing or installing option modules, SMX network modules and software upgrade chips or damage may result.

  • Page 12: Smx Network Transceivers

    1.4: SMX Network Transceivers Connection of the network wiring to the NION is made via an SMX transceiver. The network SMX transceiver daughter board is a component of every NION. This transceiver provides the network medium interface for NION network communication. There are four styles of SMX transceivers: FTXC for FT-10 (Free Topology) wire bus and star, S7FTXC for style seven wiring requirements, FOXC for FT-10 fiber point-to-point and DFXC for bi-directional fiber.
  • Page 13 S7FTXC-PCA (Style-7) Network Transceiver The S7FTXC-PCA combines two FT-10 interface ports that allow the transceiver to meet Style-7 wiring requirements. The two ports on the S7FTXC-PCA, when used with true style-7 wiring requirements, create a point-to-point type network segment allowing up to 8,000 feet between nodes that use the S7FTXC-PCA. The separate FT ports allow two twisted pair connections so that a cabling fault on one segment will not affect the other.
  • Page 14 FOXC-PCA and DFXC-PCA Fiber Optic Network Transceivers The FOXC-PCA allows up to 8db of attenuation per segment in a point to point configuration only. The DFXC-PCA can operate in either a bus or a ring format. The regenerative properties of the DFXC transceiver allow runs of up to 12db of attenuation between each node, with up to 64 nodes per segment.

  • Page 15: Section Two: Simplex 4010 Nion Installation And Configuration

    Section Two: Simplex 4010 NION Installation and Configuration 2.1: Simplex 4010 NION Connection The Simplex 4010 NION provides monitoring of the Simplex 4010 FACP . This requires the use of a Simplex 4010-9811 dual EIA-232 card installed in the Simplex 4010 panel. The 4010-9811 dual EIA-232 card provides the NION the communication connection to the Simplex 4010 panel via serial port B (P6) of the 4010-9811.
  • Page 16 Serial Connections The Simplex 4010 NION requires that a Simplex model 4010-9811 dual EIA-232 card be installed in the Simplex 4010 FACP . The NION communicates to the 4010 FACP through serial port P6 onboard the 4010-9811 card. Figure 2-2 diagrams the wiring between TB1 of the NION and P6 (Serial Port B) of the 4010-9811. Simplex 4010-9811 Dual Simplex 4010-9811 Dual Simplex 4010-9811 Dual...

  • Page 17: Simplex 4010 Nion Enclosure And Mounting

    Power Requirements and Connection The Simplex 4010 NION requires 24VDC @ 250mA nominal in G N D G N D G N D G N D G N D accordance with local code require- +24VDC +24VDC +24VDC +24VDC +24VDC ments. It can be powered by any power limited, regulated source that is UL listed for use with fire protective signaling units.

  • Page 18: Event Reporting And Acknowledgement

    Mounting NION boards within the enclosure When installing single NION boards in Simplex 4010 NION Simplex 4010 NION Simplex 4010 NION Simplex 4010 NION Simplex 4010 NION this enclosure, be sure to use the inboard set of four mounting studs as shown below.

  • Page 19: Section Three: Simplex 4010 Nion Explorer

    Section Three: Simplex 4010 NION Explorer 3.1 Simplex Explorer Overview The Simplex 4010 NION Explorer is a plug-in application that provides the ability to view panel information and NION configurations from a UniNet™ 2000 workstation. The Simplex Explorer operates much like Windows Explorer.

  • Page 20: Configuring The Nion Through Simplex 4010 Explorer

    The Simplex 4010 Explorer Main Screen consists of the following: Update button - Saves configuration changes made with Simplex Explorer to the NION. Undo button - Cancels any configuration changes made in the plug-in. Exit button - Closes the Simplex Explorer. Arrange button - Toggles the Simplex 4010 Explorer window to be always on top or moved to the background when an event occurs.
  • Page 21 NION-Simplex 4010 Configuration Menu L L L L L earn P earn P earn P earn P earn Panel Devices anel Devices anel Devices anel Devices anel Devices - This selection allows the NION to learn, or self program, all the devices associated with the Simplex 4010 panel it is connected to.
  • Page 22 NOTE: While in Data Capture Mode, no events will be sent to the UniNet™ Workstation. NOTE: The NION requestes the Revision (REV) from the panel every 15 seconds. This is used to monitor the connection and is normal. Figure 3-5: Data Capture Mode Upload NION Configuration - This option creates a file on the hard drive containing all the information stored at the NION.

  • Page 23: Index

    Index Symbols Symbols Symbols Symbols Symbols S S S S S 2DRN Board Layout Serial Communication Settings 16 J2,J3 Pin Connections 10 Serial Connections 16 J6 Pin Connections Headers for SMX Xvr 10 Simplex 4010 NION Explorer 4010-9811 dual EIA-232 15 Registering and Opening the Simplex Explorer 19 Simplex Explorer Main Form 19 E E E E E...
  • Page 24 ® For products not under NOTIFIER manufacturing date-stamp control, the warranty is eighteen (18) months from date of original purchase by NOTIFIER ® 's distributor unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.
