Fusion 8ft Versatile Slider Dolly with Track System
(SD-FUSN-00)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
8ft Track
2x End Feet
2x Safety
3x Junior
4x Adjustable
Wheels
Pin Adapters
Support Bracket
Leveling Legs
Camera Dolly with 100mm bowl
75mm
4x Elastic Stoppers
Mitchell Base 150mm Bowl
Conversion Ring
3x Allen keys
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Advertisement
Table of Contents
Related Manuals for PROAIM SD-FUSN-00
Summary of Contents for PROAIM SD-FUSN-00
- Page 1 Fusion 8ft Versatile Slider Dolly with Track System (SD-FUSN-00) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 Safety Hints ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT SERIOUS DAMAGE TO THE GEAR! NEVER LEAVE THE FASTENERS LOOSE Carefully tighten all the fasteners to prevent breakage to the equipment & any harm to crew. It ensures protection & stability. DO NOT FORGET TO SECURE THE DOLLY Always use Safety Wheels while mounting the dolly in Under-Slung or Inclined Mode.
- Page 3 Assembling the Dolly Setup • Mount the Camera Dolly onto the track, as shown. • Loosen & remove the center knob on both sides of the dolly and attach the safety wheels. • Next, re-attach & tighten the knobs. • Loosen the side knobs on both sides of the dolly for tilting the camera platform.
- Page 4 • To use 150mm Bowl Head with Dolly, add 150mm Bowl Receptacle. • To mount Mitchell base setups, remove the 100mm bowl receptacle from the dolly platform & attach the mitchell plate to it. Tighten screws using an allen key. •...
- Page 5 • Attach the junior pin adapter to the hook inserted into the support bracket & tighten it by twisting it. • Center the support bracket under the track and mount your camera setup, as shown in the image. Underslung Dolly Setup •...
- Page 6 YOUR PROAIM FUSION 8FT VERSATILE SLIDER DOLLY WITH TRACK SYSTEM ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
