External Antenna Selector Or Antenna Tuner Connections - Icom IC-756 Instruction Manual

External antenna selector or antenna tuner connections

CONNECTING THE EX-627
Coaxial cable
ANT1
ACC(2)
CONNECTING THE AH-3
NOTE: The AH-3 can be used for the HF bands only, although the [ANT1]
connector is used for both HF and 50 MHz operation. Use a coaxial antenna
switch when you operate the 50 MHz band with the AH-3 connected.
Coaxial cable (from the AH-3)
ANT1
IC-756
CONNECTING THE IC-AT500 THROUGH THE IC-2KL
To an
antenna
Coaxial cable
(supplied with
the IC-AT500)
IC-AT500
(supplied with the EX-627)
ACC cable
(supplied with
the EX-627)
Control cable
AH-3
Ground
ACC cable
(supplied with the
IC-AT500)
ANT
IC-2KL
GND
To the IC-2KLPS
Ground
INSTALLATION AND CONNECTIONS
EX-627
Ground
Long wire or optional AH-2b
ACC cable
(supplied with the IC-2KL)
Coaxial cable
(supplied with the IC-2KL)
OPC-118
2
ANT1
Transceiver
ACC(1) ACC(2)
(sold separately)
18
