Opening & safety sensor for automatic sliding doors in emergency exits
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
DESCRIPTION
1
2
3
4
5
PAS024AMR
OPENING & SAFETY SENSOR
FOR AUTOMATIC SLIDING DOORS
IN EMERGENCY EXITS
(according to EN 16005 and DIN 18650)
User's Guide for product version 0403 and higher
See product label for serial number
1.
LCD
2.
radar antenna (narrow field)
3.
radar antenna (wide field)
4.
IR-curtain width adjustment
5.
IR-lenses
6.
cover
7.
main connector
8.
main adjustment knob
9.
IR-curtain angle adjustment knob
6
7
8
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAS024AMR and is the answer not in the manual?

Questions and answers

Related Manuals for DITEC PAS024AMR

Summary of Contents for DITEC PAS024AMR

  • Page 1 PAS024AMR OPENING & SAFETY SENSOR FOR AUTOMATIC SLIDING DOORS IN EMERGENCY EXITS (according to EN 16005 and DIN 18650) User’s Guide for product version 0403 and higher See product label for serial number DESCRIPTION cover radar antenna (narrow field) main connector...
  • Page 2 HOW TO USE THE LCD? DISPLAY DURING NORMAL FUNCTIONING To adjust contrast, push and turn Negative display = active output Opening Safety the grey button simultaneously. impulse During normal function only. FACTORY VALUE VS. SAVED VALUE displayed value = saved value displayed value = factory value NAVIGATING IN MENUS Push to enter...
  • Page 3 PAS024AMR: INSTALLATION GUIDE MOUNTING IMPORTANT! The radar output parameter has to be set to « current output « (factory value). WIRING Make sure the black cable sleeves are placed on the side WITH INTERFACE WITHOUT INTERFACE of the controller! Controller...
  • Page 4 INFRARED SAFETY FIELD DOOR CLOSER CLOSER max. 9 cm** AWAY AWAY If necessary, adjust the IR-curtain Activate the visible* spots to verify the position of the IR-curtain. angle (from -7° to 4°, default 0°). * Visibility depends on external conditions. When spots are not visible, use the Spotfinder to locate the curtains. ** The distance between the inner curtain of the inside door sensor and the inner curtain of the outside door sensor should always be smaller than 20 cm.

  • Page 5: Overview Of Settings

    OVERVIEW OF SETTINGS BASIC Back More factory values for radar immunity, IR immunity, IR number and redirection shopping critical increased immunities, 1 curtain PRESETTINGS standard street env. increased immunities, redirection = motion and presence Invfreq : frequency in RAD: FIELDSIZE >...

  • Page 6: Troubleshooting

    TROUBLESHOOTING The sensor signals ORANGE LED flashes 1 x. Replace sensor. an internal fault. ORANGE LED flashes 2 x. The power supply is too Check power supply (in the diagnostics menu of the LCD). low or too high. Check wiring. Decrease the angle of the IR-curtains.

  • Page 7: Installation

    LED-SIGNAL Presence Motion detection detection LED flashes LED flashes LED flashes LED flashes LED is off quickly x times red-green INSTALLATION The sensor should be Do not cover the sensor. Avoid highly Avoid moving objects fixed firmly to avoid and light sources in reflective objects in extreme vibrations.

  • Page 8: Technical Specifications

    ASSA ABLOY Entrance Systems AB - Lodjursgatan 10 - SE-261 44 Landskrona - Sweden - www.ditecautomations.com ASSA ABLOY Entrance Systems AB hereby declares that the PAS024AMR is in conformity with the European directives 2014/53/EU (RED), 2006/42/EC (Machinery) and 2011/65/EU (ROHS).
