Simplicity Legacy Series Service & Repair Manual page 265

54" Mower Drive, Belt, Arbor & Blade Group
REF. QTY.
1 1
2 2
3 11
4 4
5 7
6 3
7 4
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 3
16 1
17 1
18 1
19 1
20 2
21 1
22 1
23 6
24 3
25 3
26 2
27 3
28 3
29 3
30 6
31 3
32 3
33 3
34 18
35 3
36 3
37 3
38 3
39 3
40 2
41 3
42 3
43 1
44 1
45 1
46 1
47 1
48 1
49 1
50 2
51 2
DESCRIPTION
GEARBOX, 54" Mower Deck (See Service Parts on page 44)
BRACKET, U, 5-1/2 x 2
LOCKWASHER, 3/8
CAPSCREW, Hex Hd, 3/8-16 x 3/4, Grade 5
NUT, 3/8-16
SCREW, Set, Sq Hd, Cup Pt, 5/16-18 x 1/2, Grade 8
CAPSCREW, Hex Hd, 3/8-16 x 1, Grade 5
STOP, Idler
WASHER, Plain, 3/8
SPACER
PULLEY, Idler, Spring-loaded
SPACER
NUT, Hex, Center Lock, 3/8-16
SPRING, Extension
WASHER
FITTING, Lube
BOLT, Carriage, 3/8-16 x 2, Grade 5
CAPSCREW, Hex Hd, 3/8-16 x 2-1/4, Grade 5
WASHER, Plain, 3/8
BUSHING
SPACER
ASSEMBLY, Lever & Hub, Idler
CAPSCREW, Hex Hd, 7/16-14 x 1-1/4, Grade 5
LOCKWASHER, 7/16
WASHER, 7/16
PULLEY, Side Arbor
SHIELD
HOUSING, Arbor, Top
ARBOR SHAFT & BEARING ASSEMBLY, Complete (Includes Ref 30, 31 & 32)
BEARING
GASKET, Foam
ARBOR SHAFT
ASSEMBLY, Housing, Bottom (Includes Ref 35)
CAPSCREW, Hex Hd, Taptite, 5/16-18 x 3/4
FITTING, Lube
SHIELD, Grass
WASHER, Shim
ADAPTER, Blade
RING, Self Locking
BLADE, Mower, 20-1/2"
WASHER, Spline
WASHER, Spring
BLADE, Mower, 16"
CAPSCREW, Hex Hd, 3/8-16 x 1-1/2, Grade 5
PULLEY, Center Arbor
BELT, V
PULLEY, Gearbox
DRIVE SHAFT, Complete (See Service Parts on page 42)
CAPSCREW, Hex Hd, 1/4-20 x 2-1/4, Grade 5
KEY
NUT, Hex, Center Lock, 1/4-20
54" Mower Drive, Belt, Arbor & Blade Group
18 - 21
18 Mower Deck Service
