Simplicity Legacy Series Service & Repair Manual page 16

1 General Information
Specifications
TRANSMISSION:
Control
Speeds @ 3600 rpm
Travel Speeds:
20 HP Kohler Model
20 HP Kawasaki Model
24.5 HP B&S Diesel Model Forward 0-8 MPH – Hi,
25 HP Kohler Model
Final Drive
PTO:
Location
Type
Control
Amp Draw
PTO rpm:
Front
Rear (Optional)
WHEELS:
Front
Rear
Tires:
Standard Tires:
Front Turf
Rear Turf
Inflation Pressure:
Front
Rear
SOUND RATING
(AT OPERATORS EAR):*
Tractor Only at Full Throttle
Tractor with 48" Mower
Tractor with 60" Mower
*Meets applicable safety standard ANSI B71.1-1996.
Shock absorber dampened
pedal w/brake return
two-speed transmission
w/traction control Hi/Lo range
control
Continuously variable,
forward and reverse
Forward 0-7 MPH – Hi,
0-5.5 MPH – Lo
Reverse 0-3.5 MPH – Hi
Reverse 0-2.5 MPH – Lo
Forward 0-8 MPH – Hi,
0-6.5 MPH – Lo
Reverse 0-4 MPH – Hi
Reverse 0-3 MPH – Lo
0-6.5 MPH – Lo
Reverse 0-4 MPH – Hi
Reverse 0-3 MPH – Lo
Forward 0-8 MPH – Hi,
0-6.5 MPH – Lo
Reverse 0-4 MPH – Hi
Reverse 0-3 MPH – Lo
Hardened spur gears
rolling contact bearings
Front
Electric clutch
Push/pull switch
5 Amp
2400
2000
Multi Trac C/S Dico
Multi Trac C/S Dico
18 x 8.5-8
26 x 12-12
12-15 psi
6-8 psi
83.9
–
86.2
SEAT:
Style/Height
Suspension
Adjustment/Positions
Armrests
MATERIALS:
Front Axle
Front Spindles
Front Wheel Bearings
Frame Side Rails
Seat Deck
Tunnel
Hood/Side Panels
Front Bumper
Foot Pads
PAINT:
Color Coat
DIMENSIONS:
25 HP Kohler & 20 HP Kawasaki
Height
Width
Length
Wheel Base
Weight with 60" Mower
Cutting Width
Cutting Height
Front Tires
Rear Tires
Turning Radius
20 HP Kohler
Height
Width
Length
Wheel Base
Weight with 48" Mower
Cutting Width
Cutting Height
Front Tires
Rear Tires
Turning Radius
24.5 HP Briggs & Stratton Diesel
Height
Width
Length
Wheel Base
Weight with 60" Mower
Cutting Width
Cutting Height
Front Tires
Rear Tires
Turning Radius
1 - 14
18" high back
Tapered spring
Seat slide w/position lock
Optional
Cast Iron
Steel – 25 mm
Precision ball
Formed steel – 7 ga.
Steel
Steel
Steel
Steel
Molded rubber – 3/8"
Powder paint
51"
44.75"
78.75"
55"
1125 lbs.
60"
1-5"
18 x 8.5-8
26 x 12-12
26"
49.5"
40.5"
77.75"
55"
1050 lbs.
48"
1-5"
16 x 7.5-8
23 x 10.5-12
26"
51"
44.75"
78.75"
55"
1460 lbs.
60"
1-5"
18 x 8.5-8
26 x 12-12
26"
