HermanMiller
Nook Table
Tools Required
Allen Key
Power Driver
How to install Nook Table
Step 1:
1.1 Attach the top plate to the leg. Use Allen key to secure two M8
flat head machine screws, to attach the plate.
Note: Tighten fasteners until snug plus ½ turn.
Nook Table
Phillips Bit
Round-out for all legs on the Nook table.
Parts Included
Work Surface
Liner
Main Panel
Return Panel
Castor (Optional)
Step 2: (For castor option only)
2.1Insert castor stem into bottom of leg until fully seated.
1
#10 Pan
Head Screw
M8 Machine
Leg
Plate
screw and
Nut
Tapping
M8 Flat Head
Screw
Screw
Dampener
Barrel Screw
Trim
1BSSGT rev B
Assembly Instructions
Clip
