Field Controls Trio Plus User Manual page 6

No Symbol Symbol
Name
Control Panel lights will dim, the air quality
indicator will turn off and the button beep
sound will be silenced.
Speed and timer are adjustable in sleep
Sleep
mode. Button luminance will return to normal
Mode
upon exiting SLEEP mode.
When the purifier is entering sleep mode, an
eight hour timer will automatically begin.
The timer can be turned off manually.
The purifier operates at maximum speed.
Turbo
Exit Turbo Mode by adjusting speed
Mode
manually or switching to another mode.
Power
Press to turn the purifier ON or OFF.
Getting Started
Setting up the TRIO Plus
Before using the appliance, remove all the packaging materials covering the
filters and padding behind the UVC lamps and place the filters back into the
appliance as described in the following steps:
Please ensure that the correct filter installation sequence is followed.
Otherwise, there may be damage to the product and the filtration
Note
efficacy of the unit may not be as effective as advertised.
Meaning
Step 1: With both hands on the upper
side of the appliance, first pull the
front case in the direction 1, then lift
the front case in direction 2.
Step 3: Remove each filter from
appliance and remove from
packaging.
Step 2: Press down on Pre-filter
screen tabs and pull outwards.
Remove packaged pre-filter from
pre-filter screen frame and then
remove filter from package.
Step 4: Remove the padding from
behind the UVC lamps.
