  • Page 1 BLADE H PELLET BOILER STOVE Upgrade www.edilkamin.com Installation, use and maintenance page...

  • Page 2: Table Of Contents

    EDILKAMIN trademark, named BLADE H 15 SERIAL NO.: Rating plate reference BLADE H 15 Declaration of performance (DoP - EK no. 199) Moreover, the company hereby declares that: the BLADE H 15 wood-pellet boiler stove fulfils the requirements of the following European directives:...
  • Page 3 • the warranty certificate accompanying the product. can request a copy from your dealer or down load it from www.edilkamin.com The warranty conditions are given in the warranty certificate accompanying the product and on the website Readers of this manual www.edilkamin.com.

  • Page 4: Safety Information

    Licensed and qualified Technical Assistance ON. Electrocution hazard. Centre/Edilkamin retailers company names • Use of improper ignition aids (e.g. are available on the Edilkamin website www. alcohol). DO NOT IGNITE OR BOOST edilkamin.com ONLY. THE FLAME WITH FLUID SPRAYS OR A FLAME TORCH.

  • Page 5: Dimensions

    DIMENSIONS BLADE H 15 (cm) - STEEL Ø 8 Ø 8* smoke outlet Ø 5 combustion air FILLING G 3/4” M RETURN G 3/4” M DELIVERY G 1/2” M *for rear exit smoke, with optional USER/INSTALLER...
  • Page 6 DIMENSIONS BLADE H 15 (cm) - CERAMIC Ø 8 smoke Ø 8* outlet Ø 5 combustion air FILLING G 3/4” M RETURN G 3/4” M DELIVERY G 1/2” M *for rear exit smoke, with optional USER/INSTALLER...
  • Page 7 DIMENSIONS BLADE H 15 (cm) - GLASS Ø 8 smoke Ø 8* outlet Ø 5 combustion air FILLING G 3/4” M RETURN G 3/4” M DELIVERY G 1/2” M *for rear exit smoke, with optional USER/INSTALLER...

  • Page 8: Technical Data

    Absorbed power in stand-by mode Power absorption during ignition 300 W Protection rating Fusibile 4 AT, 250 Vac 5x20 EDILKAMIN S.p.A. reserves the right to modify the product at its own discretion and without prior notice, with a view to improvements. USER/INSTALLER...
  • Page 9 TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COMMISSION REGULATION (EU) 2015/1185 AND 2015/1186 Manufacturer Edilkamin S.p.A. Trademak Edilkamin Model Identifier Blade H 15 Description Mechanically space heater with boiler fired by wood pellets Indirect heating functionality Direct heat output (space heat output) 2,3 kW...

  • Page 10: Unpacking

    UNPACKING Always move the stove vertically with PREPARATION AND UNPACKING suitable equipment and in compliance with The packaging materials are neither toxic nor noxious The packaging materials are neither toxic nor noxious safety regulations. and do not require special disposal. and do not require special disposal.
  • Page 11 REAR SMOKE DISCHARGE KIT A REAR SMOKE DISCHARGE KIT exists as optional. INSTALLER...
  • Page 12 ADJUSTABLE FEET WALL MOUNTING Mount the stove to the wall with the plates provided The Blade H 15 boiler stoves have adjustable feet to (a) and the brackets (b) already mounted on the adapt to uneven floors. product, or use alternative systems that guarantee The feet can be adjusted by slightly raising the boiler that the product remains stable.

  • Page 13: Installation

    INSTALLATION standard INSTALLER...
  • Page 14 INSTALLATION RIGHT-HAND SIDE HYDRAULIC FITTINGS To have the hydraulic fittings on the right-hand side, it is possible to use commercial elbows and “exploit” the “recess” (“indent”) between the pipes’ outlet and the rear of the stove, as shown in the figure below. Remove B When installing the kit, remove the rear and verify that the swivel nuts on the boiler stove’s outlet pipes are closed.
  • Page 15 STEEL CLADDING Description Reference in the figures below Quantity Top left-hand side panel n°1 Left-hand side panel n°1 Top right-hand side panel n°1 Right-hand side panel n°1 Aesthetic top edge n°1 Right profile n°1 Left external profile n°1 Left front profile n°1 Central spacer n°2...
  • Page 16 STEEL CLADDING BEFORE INSTALLING THE Levelling feet The product is equipped with feet that CLADDING, SECURE THE can be adjusted with a screwdriver from PRODUCT TO THE WALL WITH inside the product BEFORE mounting the THE BRACKETS PROVIDED TO claddings, or by slightly raising the product. MAKE SURE IT DOES NOT TIP OVER.
  • Page 17 STEEL CLADDING Fitting of the assembled left-hand side panel viti per profilo di compenso INSTALLER...
  • Page 18 STEEL CLADDING Fitting of the assembled left-hand side panel INSTALLER...
  • Page 19 STEEL CLADDING Assembling the right-hand side panel Screw on the top right-hand side panel, the external right-hand profile and the right-hand front profile. Slot the top Screw on the top right-hand side panel, the external right-hand profile and the right-hand front profile. Slot the top right-hand side panel.
  • Page 20 STEEL CLADDING Insert the assembled right-hand side panel. Insert the assembled right-hand side panel. screw on top screw on top screw INSTALLER...
  • Page 21 STEEL CLADDING Mounting the aesthetic top edge Place the aesthetic top edge by slotting it into the two pins to the right and left and fastening it with the 4 screws on Place the aesthetic top edge by slotting it into the two pins to the right and left and fastening it with the 4 screws on the front.

  • Page 22: Cladding

    CERAMIC CLADDING The Blade H ceramic cladding is divided as shown below: The Blade H ceramic cladding is divided as shown below: • • a box with the metal parts (A), indicated in the table below (3-4-5-6); a box with the metal parts (A), indicated in the table below (3-4-5-6); •...
  • Page 23 CERAMIC CLADDING Assembling the right-hand side panel (3 and 4) agganci agganci INSTALLER...
  • Page 24 CERAMIC CLADDING Assembling the side panel (2) fix fix screws screws screws screws INSTALLER...
  • Page 25 CERAMIC CLADDING Assembling the side panel (1) two top screws two top screws screws screws INSTALLER...
  • Page 26 CERAMIC CLADDING • • Regulations Regulations upper slots upper slots where the where the ceramic ceramic elements are elements are screws on screws on screws screws screws screws INSTALLER...
  • Page 27 CERAMIC CLADDING Mounting the aesthetic top edge (5) Mounting the aesthetic top edge (5) Place the aesthetic top edge by slotting it into the two pins to the right and left and fastening it with the screws on the Place the aesthetic top edge by slotting it into the two pins to the right and left and fastening it with the screws on the front.
  • Page 28 STEEL CLADDING - GLASS Description Reference in the figures below Quantity Left upper panel n°1 Lower left side n°1 Right upper panel n°1 Lower right side n°1 Aesthetic top edge n°1 TOp glass n°1 Bottom right glass n°1 Bottom left glass n°1 Filler Profile n°8...
  • Page 29 STEEL CLADDING - GLASS • Bend the upper flaps (A) to 90 °. • Leave the lower fins (B) straight. Assembling glass INSTALLER...
  • Page 30 STEEL CLADDING - GLASS Assembling the side panel INSTALLER...
  • Page 31 STEEL CLADDING - GLASS Assembling the side panel INSTALLER...
  • Page 32 STEEL CLADDING - GLASS Fix glass fixi fixi INSTALLER...
  • Page 33 STEEL CLADDING - GLASS Assembling the left side panel Assembling the right side panel INSTALLER...
  • Page 34 STEEL CLADDING - GLASS Assembling the left side panel (5) screws screws INSTALLER...
  • Page 35 HYDRAULIC INSTALLATION HYDRAULIC CONNECTIONS • Check that the hydraulic system has been properly The hydraulic connections depend on the type of arranged and that it is equipped with a sufficiently system. large expansion vessel for guaranteeing its safety. However, there are a few “general rules”. The presence of the vessel incorporated in the Below are the reference rules according to the Italian boiler stove does NOT guarantee adequate...
  • Page 36 HYDRAULIC INSTALLATION The product is equipped with: - pump - safety valve - expansion vessel (suitably sized for the volume of water of the primary circuit) Template for plumbing fittings in mm INSTALLER...
  • Page 37 HYDRAULIC INSTALLATION PUMP SPECIFICATIONS LEDS The pump has no adjustment devices. Adjustments are made via the electronic circuit board: it “starts” at minimum speed and makes adjustments based on the water temperature trend. The table below shows the LED signals and their descriptions. MEANING CAUSE SOLUTION...
  • Page 38 INSTALLATION POSSIBLE SYSTEM DESIGNS The installer can configure 4 types of systems. The relative probe inputs are already configured automatically. INSTALLER...
  • Page 39 INSTALLATION DIRECT HEATING (with optional boiler) IT is configuration “O” in the parameters. The product adjusts in relation to the water temperature and switches on/off on the basis of the room temperature (probe or thermostat T) or, at the discretion of the installer, on the ba- sis of the water temperature.
  • Page 40 INSTALLATION HEATING WITH PUFFER (inertial storage tank) IT is configuration “1” in the parameters. The product adjusts in relation to the water temperature and switches on/off on the basis of the PUFFER temperature (P). The room temperature measured by the thermostat (T) adjusts the secondary circuit pump (P2) NOTE: In Italy the systems must be separated if the power exceeds 35 kW.
  • Page 41 INSTALLATION HEATING WITH DHW STORAGE TANK (with optional boiler) IT is configuration “2” in the parameters. The product has the main aim of heating the domestic hot water storage tank. The product adjusts in relation to the water temperature and switches on/off on the basis of the room temperature (probe or thermostat T) or, at the discretion of the installer, on the ba- sis of the water temperature.
  • Page 42 INSTALLATION HEATING WITH PUFFER (inertial storage tank) AND BOILER (domestic hot water storage tank) IT is configuration “3” in the parameters. The product has the main aim of heating the domestic hot water storage tank. The product adjusts in relation to the water temperature and switches on/off on the basis of the PUFFER temperature (P).
  • Page 43 INSTALLATION In addition to the pre-set configurations, the product can be installed on integrated systems (example below) with probes and thermostats. NOTE: In Italy the systems must be separated if the power exceeds 35 kW. NOTE: Given the product’s power, we do not recommend using it to produce instantaneous domestic hot water. INSTALLER...
  • Page 44 INSTALLATION TERMINAL BOARD On the side there is a bracket with 2 terminal boards*. One terminal board (10 poles) is low voltage and the other (6 poles) is high voltage. Examples of possible connection configurations are given below. The poles are numbered on the product as below low voltage terminal board POSSIBLE CONNECTIONS NOTES...
  • Page 45 Contact the authorised Edilkamin Technical Assistance an explosive atmosphere. Any extraction fans Centre. operating in the same room or area as the product may affect its draught.
  • Page 46 INSTALLATION FLUE FLUE SYSTEM( SYSTEM(Smoke Smoke duct, duct, flue flue THE SMOKE DUCT THE SMOKE DUCT chimney pot chimney pot) ) Besides the general prescriptions applicable to the This chapter has been drawn up pursuant to European smoke duct and flue, the smoke duct: : regulations EN 13384, EN 1443, EN 1856 and EN •...
  • Page 47 INSTALLATION FLUE COMBUSTION AIR INTAKE Further to the general prescriptions, the flue must must In general, we suggest two ways to ensure a proper • only be used to discharge smoke flow of combustion air. The air must be drawn from •...
  • Page 48 The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the power of the appliance.
  • Page 49 INFORMATION ABOUT THE USE FIRST IGNITION (COMMISSIONING) PHASES • Make sure you have read and understood this manual. • Switch it on ONLY with the claddings mounted on. • Remove all flammable materials from the appliance (manuals, labels, etc.). In particular remove any labels from the glass.
  • Page 50 INFORMATION ABOUT THE USE LOADING PELLETS INTO THE TANK To access the tank, open the lid. * When the boiler stove is hot, DO NOT MAKE CONTACT between the pellet bag and the top grille. Use the glove when loading the stove while it operates and is therefore hot to the touch.

  • Page 51: User Instrucions

    : can be used for all functions at home with direct connection or away from home through an Internet connection and registration, downloadable from iOS (App Store) or Android (Play Store). By purchasing the Edilkamin optional elements included in the range: •...
  • Page 52 USER INSTRUCTIONS The views display the functions and are described in the following sections: 15:40 14.9 ° 1.2 bar - BUTTONS The display has 8 buttons: ON/OFF: to switch from the OFF mode to the ON mode. In the menus, it can be used to confirm and return to the main screen +/- to increase/decrease the set values or scroll between the menu items M: to access the menu or exit the menu items without saving OK to confirm an operation (2 seconds) or to access a menu item...
  • Page 53 USER INSTRUCTIONS THE READING AREA OF THE DISPLAY is divided in two parts: • the status bar, at the top; • the main area, at the bottom. the views display the functions and are described in the following sections In the status bar you can read: •...
  • Page 54 USER INSTRUCTIONS From the display, you can: Switching on and off will take a few minutes, • Switch from OFF to ON modes, by during which the flame must appear or go pressing and holding the ON/OFF button off. Just wait without taking any action. •...
  • Page 55 USER INSTRUCTIONS - FAN ADJUSTMENT The setting can be made with the stove turned OFF or ON. If the backlight is switched off, it can be activated by pressing any button. Pressing the button will make SET flash and, instead of the room set-point, the number of the fan being modified will appear (F1).
  • Page 56 USER INSTRUCTIONS POSSIBLE STATUSES of the product: - OFF STATUS The product is “deactivated” and will not produce heat due to manual switching off using the ON/OFF button on the remote control or due to an external contact (timer, telephone dialler). From the OFF page, press the ON/OFF button for 3 seconds to access the ON page.
  • Page 57 USER INSTRUCTIONS - MENU It can be accessed by pressing the button and the first Menu item will appear. You can scroll the menu items with the buttons and enter the item with the following button The menu items appear in the following order: 01 STAND-BY 02 PELLET LOADING 03 TIMER...
  • Page 58 USER INSTRUCTIONS - STAND-BY When the Stand-by function is active, the product switches off once the temperature set-point is reached and turns on again when the room temperature drops below the chosen value. When the Stand-by function is not active, the product sets itself to minimum power when the temperature set-point is reached.
  • Page 59 USER INSTRUCTIONS Pressing the button with the value ON activates the function and the display will propose to choose how many minutes must pass before the devices switches off in stand-by mode. (example 4 minutes) 15:36 14.9 ° STAND-BY 4 MIN buttons can be used to modify the time and the button to confirm.
  • Page 60 USER INSTRUCTIONS - PELLET LOADING Allows for loading the pellets once the screw feeder has emptied completely. Useful for the technician during the initial start-up. Available only in the OFF status. Any attempt to activate the function in other statuses will not be allowed. To access the function from the main menu (as indicated in the Menu paragraph above), press the button.
  • Page 61 USER INSTRUCTIONS - TIMER SETTINGS To access the function from the main menu (as indicated in the Menu section above), press the button. You can scroll the menu items with the buttons and enter the item with the following button 15:36 14.9 °...
  • Page 62 USER INSTRUCTIONS Choose the day of the week by scrolling the buttons (you will simultaneously see the programme for that day) and confirm with the button. day of the week 00:00 15:36 e.g. = MON = Monday 14.9 ° 14.9 °...
  • Page 63 USER INSTRUCTIONS After setting the entire day, confirm with the following button The COPY and PASTE function is available. 15:36 15:36 14.9 ° 14.9 ° 21.0 OK PASTE BUTTON Pressing the button briefly allows you to exit the programming, but the programme will not activate. USER...
  • Page 64 USER INSTRUCTIONS - TEMPERATURE SETTING FOR TIMER T1 – T2 To access the function from the main menu (as indicated in the Menu paragraph above), press the button. You can scroll the menu items with the buttons and enter the item with the following button After entering the T1-T2 function, the display will show the name of the function on the first line of the status bar and the current value of T1 on the second line.
  • Page 65 USER INSTRUCTIONS - DATE AND TIME Can be used to set the current date and time. To access the function from the main menu (as indicated in the Menu paragraph above), press the button. You can scroll the menu items with the buttons and enter the item with the following button 15:36 14.9...
  • Page 66 USER INSTRUCTIONS - °C/°F SETTING of the temperature scale (centigrade or Fahrenheit degrees) To access the function from the main menu (as indicated in the Menu paragraph above), press the button. You can scroll the menu items with the buttons and enter the item with the following button After entering the °C/°F function, the name of the function appears on the first line of the status bar and the current value on the second line.
  • Page 67 USER INSTRUCTIONS - LANGUAGE SETTING Selects the language. To access the function from the main menu (as indicated in the Menu paragraph above), press the button. You can scroll the menu items with the buttons and enter the item with the following button After entering the Language Menu item, the name of the function appears on the first line of the status bar and the current value (ENGLISH) on the second line 15:36...
  • Page 68 USER INSTRUCTIONS - DISPLAY Allows for choosing the level of brightness of the display. 15:36 14.9 ° DISPLAY 15:36 14.9 ° BRIGHTNESS USER...
  • Page 69 USER INSTRUCTIONS - INFO These readings should only be done when requested by the technician. The technician understands the diagnostic meaning of the messages and values, and may ask you to read them to him/her if you experience problems. To access the function from the main menu (as indicated in the Menu paragraph above), press the button.
  • Page 70 USER INSTRUCTIONS - SOFTWARE These readings should only be done when requested by the technician. 15:36 14.9 ° SOFTWARE USER...
  • Page 71 USER INSTRUCTIONS - DATA These readings should only be done when requested by the technician. Information of the product’s HOURS operation log can be scrolled with the buttons 15:36 14.9 ° DATA 15:36 14.9 ° DATA HOURS P1/2/3/4/5= To access the function from the main menu (as indicated in the Menu paragraph above), press the button.
  • Page 72 USER INSTRUCTIONS - ALARMS These readings should only be done when requested by the technician. The alarms are arranged from the most recent to the oldest. 15:36 14.9 ° ALARMS 15:36 14.9 ° ALARMS A4 28/12/2020 Pressing the button automatically takes you to the first level. - SCREW FEEDER ON-OFF FOR THE TECHNICIAN ONLY (ON INDICATION OF THE AFTER-SALES DEPARTMENT) - PELLET LEVEL SENSOR FOR THE TECHNICIAN (ENABLING)
  • Page 73 USER INSTRUCTIONS: TECHNICAL MENU - TECHNICAL MENU (for TECHNICIANS ONLY) Accessible only to technicians with the appropriate password. Once the password has been entered, confirm with the button. If you enter with the installer password (1111) you can only access the NOTES inappropriate changes can cause installer parameters/settings:...
  • Page 74 USER INSTRUCTIONS: TECHNICAL MENU - PELLET TYPE You can scroll the Technical Menu items with the buttons until you reach “PELLET TYPE” 15:36 14.9 ° PELLET TYPE Enter the Pellet type (%) setting with the button and modify the value with the buttons Pressing the button automatically takes you to the first level.
  • Page 75 USER INSTRUCTIONS: TECHNICAL MENU - CONFIGURATION You can scroll the Technical Menu items with the buttons until you reach “CONFIGURATION” Enter the “CONFIGURATION” setting with the button and modify the value with the buttons Pressing the button automatically takes you to the first level. 15:36 14.9 °...
  • Page 76 USER INSTRUCTIONS: TEMPERATURE MENU - “TEMPERATURES” on the display (setting of the water temperatures) Allows you to set the boiler temperature and the accumulator temperature. If the external probe is active, it allows you to set the climatic curve instead of the boiler temperature. To access the function from the main menu (as indicated in the previous paragraph ), press the button...
  • Page 77 USER INSTRUCTIONS: VARIOUS MENUS - BOILER SET-POINT it is possible to set the water temperature for the product (BOILER on the display) 15:36 14.9 ° BOILER SET-POINT Depending on the configurations, the temperatures are displayed. Example: 15:36 14.9 ° BOILER SET-POINT 60.0°C USER...

  • Page 78: Maintenance

    MAINTENANCE DAILY MAINTENANCE These jobs should be done with the product off, cold and preferably disconnected from the mains. A suitable vacuum cleaner is required. Disconnect the product from the Make sure that the grate is power supply. properly placed in its Failure service product...
  • Page 79 MAINTENANCE DAILY MAINTENANCE 1. “Rub the cleaning rod under the pellet loading cover with the removable handle supplied USER/INSTALLER...
  • Page 80 MAINTENANCE 1. Open the combustion chamber door (P) using the removable handle. 2. Empty the ash tray (B) and grate (C) into a non- flammable container (the ashes may still contain embers and/or hot parts) or vacuum if cold. Vacuum the interior of the combustion chamber, the bed, and the compartment around the burning pot into which the ash falls.
  • Page 81 MAINTENANCE WEEKLY MAINTENANCE With the product switched off and cold, vacuum the inspection window beneath the combustion chamber (*) To access it: • open the door of the lower front panel using the removable handle • remove the deflector (D) which merely rests on it After cleaning the element, put the deflector back on and close the door of the lower front panel Make sure you have correctly repositioned the deflector after cleaning: it should lie horizontally between the two screws...
  • Page 82 MAINTENANCE SEASONAL MAINTENANCE Technical interventions carried technical Please contact your local retailer and/or an Edilkamin assistance centre) technician if spare parts are needed. This consists of cleaning the stove inside and out. Technical interventions must be carried out by a...
  • Page 83 SPARE PARTS For any spare parts, contact your dealer or technician. Licensed and qualified Technical Assistance Centre/ Edilkamin retailers company names are available on the Edilkamin website www.edilkamin.com ONLY. Use of non-original spare parts may cause product hazards, exonerating Edilkamin from any liability and damage caused, interrupting the warranty as a result of tampering.

  • Page 84: Troubleshooting

    TROUBLESHOOTING If problems occur, the product shuts itself off automatically. The display will show the reason (see below). 15:36 14.9 ° BURNING POT DIRTY MESSAGE PROBLEM SOLUTION • Check that the combustion chamber door is closed A01 burning pot displays when the combustion •...
  • Page 85 TROUBLESHOOTING MESSAGE PROBLEM SOLUTION • Check the type of pellet (contact the technician if in Shutdown due to exceeding doubt) maximum smoke temperature. • contact the technician Switching OFF due to excessive • see HO7 overheating of the product Shutdown due to gearmotor •...
  • Page 86 If the water in the product reaches a temperature of 85°C, the product shuts down without switching to alarm mode. The text STBY appears on the display next to the room temperature. The product is working, but it must be serviced by an authorised Edilkamin technician. MAINTENANCE (SIGNAL THAT DOES NOT CAUSE SHUTDOWN) A spanner symbol will appear on the display after 2,000 hours of operation The product is working, but it must be serviced by an authorised Edilkamin technician.
  • Page 88 Licensed and qualified Technical Assistance Centre/Edilkamin retailers company names are available on the Edilkamin website www.edilkamin.com ONLY. *942243-GB* w w w . e d i l k a m i n . c o m cod. 942243-GB 10.21/A...
