Manufacturer:
Model Number(s):
Minimum Core Module Version:
Document Revision Date:
O
S
VERVIEW AND
The ELAN IP Amps are multizone, and multisource audio switchers that can be controlled by the ELAN
software using IP. Using Dante, the various chassis can communicate and share/stream sources over IP.
T
HE FOLLOWING FEATURES ARE SUPPORTED
Source and Volume control: Each zone has independent control of the source selection and volume
control
Independent Zone Settings: Each zone has a prebuilt settings page with: Loudness, 5 band
customizable EQ, and Do Not Disturb (DND) settings
Configurable zone outputs: The outputs are independent from zones and can be assigned to any zone
for a very flexible installation. Using Dante, you can expand the number of chassis and therefore the
number of zones.
12 V Trigger outputs/Audio Sense Inputs: The EL-IPD-MTX-8CH, EL-IPD-PRE-MSI, and EL-IPD-AMP-
EXT all come with 3 12-volt trigger outputs, and also with the ability to detect audio inputs. These can be
used by configuring event maps.
Doorbell/Zone Paging: The EL-IPD-MTX-8CH and EL-IPD-PRE-MSI come with a dedicated doorbell
source that can be used with an ELAN SC100 or G1 to ring a doorbell or send a page through multiple
zones.
T
HE FOLLOWING FEATURES ARE
Control from HC Controllers: Only SC2, SC 10, SC100, and G1 can be used for control.
.
Any feature not specifically noted as supported should be assumed to be unsupported.
ELAN IPD Multi Chassis
EL-IPD-MTX-8CH
EL-IPD-PRE-MSI
EL-IPD-AMP-EXT
EL-IPD-PRE-SSI
EL-IPD-NAC-EXT (Dante Network Card)
8.5.2.0
06/25/2020
F
UPPORTED
EATURES
:
NOT
SUPPORTED
ELAN Integration Note
:
1 of 11
Advertisement
Table of Contents
Related Manuals for Elan EL-IPD-MTX-8CH
Summary of Contents for Elan EL-IPD-MTX-8CH
- Page 1 Doorbell/Zone Paging: The EL-IPD-MTX-8CH and EL-IPD-PRE-MSI come with a dedicated doorbell source that can be used with an ELAN SC100 or G1 to ring a doorbell or send a page through multiple zones. HE FOLLOWING FEATURES ARE SUPPORTED Control from HC Controllers: Only SC2, SC 10, SC100, and G1 can be used for control.
- Page 2 Networking Requirements The network is key. You MUST follow these steps to have a good experience Unicast: Basic Switching: You must use Gigabit Switches • Do not connect Dante device directly to a router • Do not cascade switches – use a single switch as the hub •...
-
Page 3: Installation
VERVIEW 1) Make all chassis connections. 2) If using EL-IPD-MTX-8CH or EL-IPD-PRE-MSI, make sure the EL-IPD-NAC-EXT card is installed 3) Add the device to your configuration. This can be done in one of three ways: a. Using AD/AC (auto-discover/auto-configure) from the discovery tab in Configurator b. - Page 4 5) Assign and configure your sources: Analog sources: Stereo: Everything should be pre-configured so just assign a source as normal Set the input gain, if needed Mono: Change the Mode dropdown and select Mono Change the Input dropdown and select the appropriate single input connected ...
- Page 5 6) Configure the zone outputs The outputs are completely configurable to the zone needs. You can assign any number of outputs to a zone. The max zones configurable on the chassis is 12 (mono outputs) By default, all zones are pre-configured to use stereo pair outputs ...
- Page 6 0-100 -Sets the minimum volume allowed on the turn on. If the last volume was lower, it will be adjusted up 8) It is recommended to delete any zones not being used from the ELAN driver. 6 of 11...
-
Page 7: Chassis Options
HASSIS OPTIONS Next to each chassis in configurator there is a cog you can click which will bring up a pop-up menu where you can adjust options for the chassis that have been added to the driver. The left pop-up window below will be for MTX-8CH, PRE-MSI, and AMP-EXT. The Right is the SSI Pressing Configure Device will bring up another pop up menu. -
Page 8: Led Operation
Enable Low Power Mode: Low power mode forces the chassis to go to sleep after a certain period of inactivity. When in low power mode the chassis can take up to 20 seconds to wake up and start playing. When not in low power mode the chassis will reduce power when idle; however, it will quickly wake up Flash LED Start: This causes the power and status LEDs on the front of the chassis to start blinking to identify the chassis. -
Page 9: Settings Page
ETTINGS 1) 5 band Equalizer 2) DND Do Not Disturb; will block zone interrupts like zone paging & doorbell chimes 3) Loudness This option will boost the low-end frequencies at lower volumes 4) Reset Will reset the 5 band EQ back to 0db 5) Presets ... -
Page 10: Common Mistakes
Front Panel LED Reference Chart: Low Power Mode Enabled after Factory Reset If you factory reset the EL-IPD-MTX-8CH or EL-IPD-PRE-MSI while they are using the NAC card it will enable low power mode by default. To Reset MSI/MTX/EXT Chassis to out of box defaults With the chassis powered on, use a small pin press and hold the reset button on the back of the chassis for 20 seconds. - Page 11 PRE-SSI not playing audio The PRE-SSI has a switch on the back the allows the input to be changed between Optical, Coax, and Stereo Analog. Make sure the switch is on the correct source. PRE-SSI can only stream to 2 chassis simultaneously while in unicast. Must change to multicast for more.
