Page 3: Organization
Purpose of This Manual This manual provides step-by-step installation instructions and connection examples, along with basic user information for installation and ongoing use of the A12 Twelve Channel Amplifier. This manual is written for the installer of this equipment. Organization... - Page 4 —Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical shock from lightning. Do not use a telephone to report a gas leak if the leak is in the vicinity of the ELAN electronic equipment because of risk of fire or explosion.
- Page 5 When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip over. Disconnect Device —Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain operable. © ELAN Home Systems 2009 • All rights reserved. Page III...
- Page 6 E L A N H O M E S Y S T E M S INSTALLATION MANUAL Page IV © ELAN Home Systems 2009 • All rights reserved.
-
Page 7: Table Of Contents
........................20 Operations and Settings Chapter 4: ....................21 Troubleshooting Chapter 5: ......................23 Appendix A: Specifications ....................... 25 Appendix B: Rack Mounting ......................26 Warranty ..........................Back Page © ELAN Home Systems 2009 • All rights reserved. Page V... - Page 8 E L A N H O M E S Y S T E M S INSTALLATION MANUAL Items in package: • A12 Power Amplifier • Power Cord • Installation Manual Page VI © ELAN Home Systems 2009 • All rights reserved.
-
Page 9: Introduction
AC Power Considerations The A12 requires 4 Amps of AC current. The A12240 (240V version) requires 2 Amps of AC current. When design- ing any whole house system using multichannel amplifiers, make sure to provide adequate provisions for all elec- tronic equipment to be installed. -
Page 10: A12 Functions & Indicators
Table 1-1:Front Panel Item Function POWER LED - Glows Blue When Power Switch is ON and Unit Plugged In STATUS LED - Glows Green When Any Channel is ON Page 2 © ELAN Home Systems 2009 • All rights reserved. -
Page 11: Rear Panel
TYPE FUSE Figure 1-2: A12 Rear Panel Table 1-2: Rear Panel Item Function FUSE: A12 - Replace with T4.0AL Type Fuse A12240 - Replace with T2.5AL Type Fuse POWER SWITCH TRIGGER INPUTS (6) SYSTEM TRIGGER IN/OUT BUS MODE DIP SWITCHES (12) -
Page 12: System Design
Figure 2-1: System Design Pre-Wire WIRING CONSIDERATIONS • Speaker Wires 28-16 AWG Speaker Wire • Audio Cables RCA Patch Cables • Triggers 2 Conductor Wire w/ 3.5mm mono connector Page 4 © ELAN Home Systems 2009 • All rights reserved. -
Page 13: Multi-Room Applications
Trigger options, the A12 can be customized for even the most complex systems. Independent Stereo Zones The A12 is designed to easily power six independent stereo zones without any special setup procedures. This is the standard configuration for most multi-zone audio distribution systems. In the drawing below, each pair of speakers will have independent line-level volume control. - Page 14 INSTALLATION MANUAL Two Room Stereo Zone By using the A12’s Buffered Loop Outputs, an additional pair of speakers can be added to a zone. In this example, both pairs of speakers will ramp volume up and down simultaneously. Two Room Stereo Zone •...
-
Page 15: Stereo Zone W/ Mono Sub-Zone
• Bus Mode DIP Switches in Default DIRECT Position All Speakers Volume Ramps Up & Down Together ZONE OUTPUTS RCA ‘Y’ Cable Figure 2-4: Stereo Zone with Mono Sub-Zone © ELAN Home Systems 2009 • All rights reserved. Page 7... -
Page 16: S66A Application
ELAN’s S66A Integrated Multi-Room Controller has built-in amplification for six stereo zones as well as six sets of preamp outputs for the addition of sub-zones. The A12 is ideally suited to amplify these subzones using rotary or electronic volume controls if separate volume up/down functionality is desired in the sub-zones. -
Page 17: S86A Application
ELAN’s S86A Integrated Multi-Room Controller has built-in amplification for six stereo zones as well as six sets of preamp outputs for the addition of sub-zones. The A12 is ideally suited to amplify these subzones using rotary or electronic volume controls if separate volume up/down functionality is desired in the sub-zones. -
Page 18: S128P Application
ELAN’s S128P Integrated Multi-Room Controller has variable preamp outputs for eight stereo zones as well as eight sets of fixed preamp outputs for the addition of sub-zones. The A12 is ideally suited to amplify these subzones using rotary or electronic volume controls if separate volume up/down functionality is desired in the sub-zones. -
Page 19: Chapter 3: A12 Connections
The term BUS is defined as the ability to route a signal from one place to another. Traditional busing is done using audio patch cables to route these signals. The use of Bus Switches, such as the ones on the A12, eliminates the need for additional patch cables and adds to the flexibility of signal routing. -
Page 20: Stereo Bussing
The example below shows the preamp output of an A/V Receiver being distributed throughout the home in stereo using the BUS INPUT of the A12. A second A12 can be added for six additional pairs of speakers via the Bus Loop Outputs. -
Page 21: Mono Bussing
INSTALLATION MANUAL Mono Bussing This example is a variation of the previous one. The first A12’s Bus Loop Outputs are 'Y’d' to create a summed L/R signal, allowing the addition of twelve monaurally-wired speakers. Stand-Alone System w/ A/V Receiver (Mono) •... -
Page 22: Elan Multi-Room Examples
ELAN Multi-Room System Examples ‘Bussing’ the audio from a Zone Output of an ELAN multi-room controller is an easy way to create a large ‘wide cov- erage zone’ without using any additional patch cables. The following diagrams show examples of how both stereo and mono ‘wide coverage zones’... -
Page 23: Bussed Mono Wide Coverage Zone
• ELAN Multi-Room Controller Zone Outputs 1-3 to A12 Inputs 1-6 • ELAN Multi-Room Controller Zone Output 4 to A12 BUS INPUT R Using RCA 'Y' Cable Each Zone's Speakers Have Independent Volume Wide Coverage Zone's Speakers Volume Ramps Up &... -
Page 24: Direct Input Bussing
ELAN Multi-Room System w/ Direct Input Bussed Mono Zones • ELAN Multi-Room Controller Zone Outputs 1-3 to A12 Inputs 1, 3, & 5 OR Inputs 2, 4, & 6 Using RCA 'Y' Cables Each Zone's Speakers Have Independent Volume RCA ‘Y’... -
Page 25: Dip Switch Settings
(Sending CH. 2, 4, 6, 8, 10, or 12 to CH. 1, 3, 5, 7, 9, or 11) (Sending Right Bus Input to Left & Right Channels) Figure 3-7: DIP Switch Settings © ELAN Home Systems 2009 • All rights reserved. Page 17... -
Page 26: Triggers
INSTALLATION MANUAL Triggers Each channel pair of the A12 has its own Remote Turn On/Muting circuit (TRIGGER INPUTS 1/2-11/12). Individual channel pairs can be muted or un-muted independently of any others. A SYSTEM TRIGGER IN port allows all chan- nels to turn on or mute simultaneously. All TRIGGER INPUTS can receive 5-24 Volts AC or DC. The 12 Volt DC SYSTEM TRIGGER OUT can be used to turn on other equipment, additional A12s or other amplifiers, or to perform automated functions desired by the user. -
Page 27: System Trigger In
SYSTEM TRIGGER OUT Whenever the A12 is powered On an any channel is On, the SYSTEM TRIGGER OUT becomes active. This output sends a +12VDC 100mA signal to other devices with a Trigger Input. Examples of proper usage of the SYSTEM TRIG- GER OUT include muting/un-muting other amplifiers, triggering the switched outlets of a Z•Power Controller, or trig-... -
Page 28: Speaker Connections
4. Lift up each flip-lock connector until it is locked in the up position. Place the bare lead from each speaker wire into the holes of the flip-lock terminal of the A12, maintaining the polarity of each lead (+ to +, - to -). -
Page 29: Chapter 4: Operations And Settings
Chapter 4: Operations & Settings Setting Channel Levels The A12 features independent Level Adjustment Pots for each of its twelve channels. Use a small Phillips screw- driver to independently adjust each channel of the amplifier for the specific speakers and environmental conditions of the area it is powering. -
Page 30: Default Mode
E L A N H O M E S Y S T E M S INSTALLATION MANUAL Turn-On Modes Use any of the following methods to mute/un-mute the A12: Default Mode • No TRIGGER INPUTS are connected. • AUDIO SENSE button is Off. -
Page 31: Chapter 5: Troubleshooting
3. Faulty wiring 3. (a) Make sure volume controls are not hooked up backwards. (b) Check for shorts in wiring (see item 2 in “No audio…”). © ELAN Home Systems 2009 • All rights reserved. Page 23... -
Page 32: Technical Support
Technical Support If, after carefully following the steps in the Troubleshooting section, you are unable to resolve issues with the installation or operation of the A12, please call ELAN Technical Support at 1-800-622-ELAN (3526). Page 24 © ELAN Home Systems 2009 • All rights reserved. -
Page 33: Appendix A: Specifications
Dimensions w/ Feet (2U w/o Feet) 17 W x 4 1/8 H x 14 D (in) 432 W x 105 H x 356 D (mm) Weight 20 lbs/9.07 kg © ELAN Home Systems 2009 • All rights reserved. Page 25... -
Page 34: Appendix B: Rack Mounting
RMK3 Rack-Mount Kit When mounting the A12 amplifier in an equipment rack, use ELAN’s RMK3 Rack Mount Kit for secure mounting and proper ventilation. The RMK3 requires three rack spaces. To install the RMK3 into a standard 19” equipment rack: 1. -
Page 36: Limited Warranty
ELAN in writing, ELAN shall repair or replace the item at the company’s option. This warranty shall not apply (a) to equipment not manufactured by ELAN, (b) to equipment which shall have been installed by other than an ELAN authorized installer, (c) to installed equipment which is not installed to ELAN’s specifications, (d) to equipment...
