- Page 1 D1650/D1651 16 CHANNEL DIGITAL POWER AMPLIFIER I N S T A L L A T I O N M A N U A L A N D U S E R © S G U I D E SIXTEEN CHANNELS...
-
Page 2: Introduction
The D1650 uses an Audio Bus system that allows inputs and The D1650 is very powerful and should have its own outputs to be combined in many ways without the dedicated 15 Amp AC circuit. If a dedicated circuit use of extraneous patch cables. -
Page 3: Safety Information
—The appliances should be connected to a power supply only of the type described in the operating instruc- tions or as marked on each appliance. If you are not sure of the type of power supply to your home, consult your authorized ELAN deal- er or local power company. - Page 4 —Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of elec- trical shock from lightning. Do not use a telephone to report a gas leak if the leak is in the vicinity of the ELAN electronic equipment because of risk of fire or explosion.
-
Page 5: Table Of Contents
Bus Mode................13 Triggers................... 14 3. Setup Setting Channel Levels............15 Lockout................... 15 Factory Default............... 16 Changing LED Brightness............. 16 4. Troubleshooting ..............17 Warranty ..................Back Page © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 5... -
Page 6: System Overview
Weight ....... . 50 lbs/22.68 kg Page 6 © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04... -
Page 7: Features
Features ‘Class T’ Design Digital Volume Level Set/Lockout ‘Class T’ allows the D1650 to deliver its full rated All channel volume levels are matched to within power from all sixteen channels simultaneously and 0.3dB, making volume setup easy, accurate, and is 90% efficient so that the amplifier does not waste repeatable. -
Page 8: Class 'T' Explained
In some Class D amplifiers, this high- frequency noise is not completely filtered out, resulting in high frequency distortion. Page 8 © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04... -
Page 9: Connections And Applications
Independent Stereo Zones Buffered Loop Outputs allow sharing of sources. The D1650 is set up to easily power eight independ- Stereo and Mono Bus Modes make configura ent stereo zones right out of the box. This is the tion a logical process. -
Page 10: Two Room Stereo Zones
INSTALLATION MANUAL Two Room Stereo Zone By using the D1650’s Audio Loop, an additional pair of speakers can be added to a zone. In this example, both pairs of speakers will ramp volume up and down simultaneously. ELAN Multi-Room Controller... -
Page 11: Stereo Zones With Mono Sub-Zones
Line Outputs 1 & 2 to RCA ‘Y’ Cable RCA ‘Y’ Cable to Line Input 3 All Speakers Volume Ramps Up/Down Together Speaker Outputs Coincide w/ Line Inputs © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 11... -
Page 12: Mono Zones
The use of mono zones also increases the capacity of the amplifier...up to sixteen mono areas can be powered from one D1650. In this example, four channels of the D1650 are configured in mono to run four speakers ELAN Multi-Room Controller “Y”... -
Page 13: Bus Mode
Connect Each Pair of Speaker Outputs to a High Power All Speakers Volume Ramps Up/Down Together Volume Control All Speaker Pairs Volume Ramps Separately w/ High Power Volume Controls. © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 13... -
Page 14: Triggers
D1650/D1651 INSTALLATION MANUAL Triggers application gives additional control in advanced Each channel pair of the D1650 has its own Remote systems. Examples include: Zone Specific Trigger Turn On/Muting circuit. Individual channel pairs can Outputs from an ELAN Multi-Zone Controller, multi- be turned on or muted independently of any others. -
Page 15: Setup
POINT WHERE THEY CAUSE THE RED Please Note: Whenever the Front Display is lit (dur- CLIPPING LEDS TO LIGHT UP. ing volume adjustment, for example), ACE clipping elimination circuitry is disabled. © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 15... -
Page 16: Factory Default
D1650/D1651 INSTALLATION MANUAL Factory Default When your D1650 arrives, it is set to a FACTORY DEFAULT condition. At some point during the life of this amplifier it may be necessary to put the unit back into Factory Default mode. If this unit is... -
Page 17: Troubleshooting
Check for Proper Input/Output connections at Volume Control. INPUT Comes from Amplifier, OUTPUT Goes to Speakers. © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 17 Page 17... - Page 18 Audio Very Distorted in Areas Set Impedance-Match Settings 1. Impedance-Match Settings Using Volume Controls Correctly. Incorrect 2. Using Incompatible Volume Use Volume Controls Rated for 50 Control Watts or Higher. Page 18 © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04...
- Page 19 ELAN HOME SYSTEMS D1650/D1651 INSTALLATION MANUAL Notes: © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 © ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 19 Page 19...
-
Page 20: Limited Warranty
Except as may be expressly provided and authorized in writing by ELAN, ELAN shall not be subject to any other obligations or liabilities whatsoever with respect to equipment manufactured by ELAN or services rendered by ELAN.
