1.1.6.1 Local LAN Port
This network is used to connect the Video door phone to a second LAN using a wire (with Internet access).
The parameters that can be configured are the following ones:
• IP address: i.e. the address which identifies the Video door phone on the LAN (enter a static IP
address coherent with the IP address of the router and its subnet mask; the address must not belong
to the "POE Port" network).
• MAC address: read-only parameter.
• DHCP: enable the parameter if there is a DHCP server in the system. In this case all parameters will
be configured automatically.
• Network mask: enter the data of the network in which the video door phone is located.
• Gateway: enter the data relating to the network in which the video door phone is located.
• DNS Server: enter the data relating to the network in which the video door phone is located.
• Status: parameter that can have 2 values, ''Disabled'' or ''Enabled'' depending on whether you want
to enable the network.
For Network Mask, Gateway and DNS Server parameters, it may be necessary to contact the network
administratore.
If all parameters have been entered correctly, after pressing the ''Confirm'' button, a second icon
will be displayed in addition to the one already present for the Ipercom network.

1.1.7 WiFi network

The WiFi network is used for wireless connection of the video door phone to a second LAN (which may
have Internet access). When the WiFi network has been activated by pressing the corresponding button
in the top right corner, the video door phone scans the networks.
