Printing speed / flow rate:
The printing speed and extrusion volume can be changed as a percentage of the
original� Use the reset button to return to the G-code values�
Caution!
In Renfert mode, the printing parameters are stored for a perfect printing
result. All of the necessary settings for orthodontic applications are opti-
mally pre-configured and tailored to the filament. This ensures a high level
of process reliability and simplicity. Changing these settings modifies the
pre-installed parameters. In this case, Renfert does not guarantee printing quality.
Backlight / brightness of the display:
Changing the brightness of the display backlight�
Object fan control
Set the rotational speed using the slide control or set a minimum/maximum rota-
tional speed using the

10.2.3 Pause next layer

The "pause next layer" function stops printing when printing of the current layer has finished.
Activating the "pause next layer" function:
⇒ Press the button (see Fig. 61).
♦ The "pause next layer" function is activated.
♦ The icon shown changes to
♦ Once the layer is complete, the printer switches to the pause menu�
Deactivating the "pause next layer" function:
⇒ Press the button (see Fig. 61).
♦ The "pause next layer" function is deactivated again.
♦ The icon shown changes to
♦ Printing is resumed without interruption�
10.2.4 Pause
The pause function can be used, for example, to replace the filament.
⇒ Press the button (see Fig. 61).
♦ The icon changes to
♦ Printing is interrupted
♦ The print head is moved to the left edge so that the object is not damaged
when a new filament is inserted.
If you would like to replace the filament, use the
load / load the filament and proceed as described in Chap. 6.6 / 6.4.
Resuming printing:
⇒ Press the icon�
♦ The print head moves back to the object
♦ Printing is resumed�
10.3

Printing with SIMPLEX print

If printing is carried out using the SIMPLEX print program, printing is controlled
exclusively via SIMPLEX print.
Only the main menu is shown on the SIMPLEX 3D filament printer.
Actions should not be performed via the display�
The options described in the previous chapter (10.2) are only available with SIM-
PLEX print.
The instructions for SIMPLEX print are contained in the instructions for SIMPLEX
sliceware�
/ buttons�
�
�
�
- 29 -
/ or / buttons to un-
en
Fig. 62
Fig. 63
Fig. 64
Fig. 65
