6

Other settings

In the "Getting started" section, the following items from the SETTINGS menu are already explained:
en
• Setting the language�
• Setting the temperature unit�
• Connecting to a Wi-Fi network.
• Leveling the print bed�
• Configuring an e-mail address for the FMS system.
• Calibrating an FMS system.
Additional options in the SETTINGS menu are presented below.
6.1

Setting the date/time / resetting the operating hours meter

A video on this topic is provided under the following link
www.renfert.com/simpl-11-en
You can set the date/time and reset the operating hours meter. This function
helps you to track operating hours between maintenance work�
⇒ Select the SETTINGS menu.
⇒ Use the right arrow
⇒ Press the button with the clock icon
⇒ Use the arrows
⇒ Use the arrows
⇒ Press the lower left arrow
The operating hours meter, which can be used to track the time elapsed
between two maintenance sessions, can be reset with the reset button
The operating hours of the last reset are saved under "Last reset".
6.2 Setting the display backlight
⇒ Select the SETTINGS menu.
⇒ Press the button with the light bulb icon
⇒ Adjust the brightness using the slide control or switch it on or off using the
buttons�
⇒ Press the lower left arrow
6.3 Activating the fan
⇒ Select the SETTINGS menu.
⇒ Press the button with the fan icon
⇒ The fan can be selected by pressing the arrow buttons
♦ The name of the fan to be controlled is shown on the display:
- Object fan
- Extruder fan
- Case fan
⇒ Set the rotational speed using the slide control or switch it off / set the maxi-
mum rotational speed using the
The rotational speed of the extruder fan can only be reduced when the ex-
truder temperature is below 60 °C [140 °F].
The extruder and case fans are automatically switched off again after 60
seconds.
and via the QR code shown.
�
to go to page 3 (as shown here in the image).
�
/ to toggle between hour / minute / year / month / day.
/ to set the date and time�
until you are back in the main menu�
�
�
until you are back in the main menu�
�
�
/ buttons�
/ at the top:
- 20 -
Fig. 39
.
Fig. 40
/
Fig. 41
Fig. 42
Fig. 43
