3.2
Scope of delivery
1 SIMPLEX 3D filament printer
1 Filament guiding tube
en
1 Filament spool holder
1 Filament spool: SIMPLEX study model
1 Filament sensor (FMS)
1 Cover
1 Door including lock and key
1 USB flash drive
1 Power cord
1 Power adapter set
4
Startup
The unit must be stored at room temperature for at least 3 hours before startup.
Do not apply force to the unit during unpacking, setup, operation, or maintenance.
4.1
Unpacking and setup
A video on this topic is provided under the following link
www.renfert.com/simplex-1-en
⇒ Place the shipping box on a flat surface on the floor. Ensure that you have enough space
available�
⇒ Open the shipping box. It contains three boxes:
- Unit
- Cover
- Accessories box
⇒ Remove the three boxes.
⇒ Carefully open the box with the unit.
⇒ Remove the foam insert�
⇒ Carefully remove the accessories box provided. It protects the extruder during transport. The box pro-
vided contains the accessories for the SIMPLEX 3D filament printer.
⇒ Lift the SIMPLEX 3D filament printer out of the shipping box by gripping the insides of the frame.
Please note the weight of the printer and ask a second person to assist you if necessary.
When removing, be careful not to touch the extruder and the electronics.
The SIMPLEX 3D-Filament-printer is not suitable for beeing operated in the patient environment,
e.g. the treatment room.
⇒ Place the SIMPLEX 3D filament printer on a stable and level surface with sufficient space around the
unit�
Do not cover the ventilation openings on the rear of the unit
⇒ Ensure that the on/off switch and power cord are easily accessible.
⇒ Using the wire cutters, remove the two cable ties that secure the print bed�
Caution: Do not damage the Kapton film!
⇒ Remove the door, which is located under the print bed�
⇒ Carefully open the box with the cover so as not to damage the contents.
⇒ Remove the cover and set it aside carefully for subsequent assembly�
and via the QR code shown.
- 8 -
1 USB A-B cable
1 Allen keys (set of 5)
1 Distance card
1 Replacement nozzle 0�4mm
2 Valve keys
1 Spatula
1 Wire cutters
1 PTFE grease (in dosing syringe)
1 Operating instructions
