- Page 1 Pokayoke Receiver TW-800R-SLNX INSTRUCTION MANUAL V1.20 Please use this operation manual correctly on reading well. Please keep it carefully to be able to read immediately, when required.
-
Page 2: Table Of Contents
Table of Contents 1.Outline ..................................1 2.Body and Accessories ............................2 3.Safety Precautions (Be Sure to Read This) ......................3 4.Name of Each Part ..............................7 5.Installation ................................9 6.Setting Method ..............................11 6-1.Pairing (Registration) ............................. 11 6-1-1. Pairing procedure ..........................11 6-1-2. Error indication on pairing ........................12 6-1-3. -
Page 3: Outline
TW-800R-SLNX 1.Outline The LAN connection type POKAYOKE receiver TW-800R-SLNX(hereinafter called “receiver”) is a receiver equipped with a LAN connection function and two-point external output. The receiver is used by pairing it with various tools equipped with POKAYOKE transmitter (hereinafter called “transmitter”) TW-800T or HRF-2402. -
Page 4: Body And Accessories
TW-800R-SLNX 2.Body and Accessories Receiver TW-800R-SLNX AC Adapter ADB24050 (Cable 1.5m (4.9ft)) TW-800R-SLNX body x1 Output 1 (Red) Output 2 (Red / White) COM (Black) Output Cable TW-SCLO-4 (1.8m (5.9ft)) Options ・Desktop Stand TW-SCDS01 ・Wall mounting bracket TW-SCLF01 TW-SCLF01×2 Mounting screw M3 x L5 x 4pcs... -
Page 5: Safety Precautions (Be Sure To Read This)
TW-800R-SLNX 3.Safety Precautions (Be Sure to Read This) This section describes the matters to be observed in order to prevent harm to the users and other persons and damages to the property. ■ The following marks and displays classify and describe the extent of harm and damage caused by failing to observe the display content and using this product wrongly. - Page 6 TW-800R-SLNX ■Handling the AC adapter Be sure to observe the followings in order to prevent the accidents such as heat generation, damage, or ignition of AC adapter. ●Do not place the AC adapter close to fire or insert them into fire. Or they may be burst and ignited, resulting in the accident.
- Page 7 〇Also contact us in case of any trouble such as harmful radio interference to specified low-power radio stations for mobile objects identification or amateur radio stations. TW-800R-SLNX is equipped with the built-in wireless module HRF-2402. HRF-2402 Certified Countries: Japan, Canada, USA, Mexico, China, Thailand, Vietnam, Philippines and India.
- Page 8 TW-800R-SLNX I Information about ISED Standard. This device complies with Industry Canada’s applicable license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 9: Name Of Each Part
TW-800R-SLNX 4.Name of Each Part ⑫ ① ④ ⑤ ② ③ ⑪ ⑧ ⑥ ⑦ ⑨ ⑩ The LED lights green when the receiver receives the signal from the transmitter. The display varies depending on each mode. ・Blink in green: Pairing mode (blinks every 50ms) ・Lit in green: Received a signal from the transmitter (lit for 50ms) - Page 10 TW-800R-SLNX The network monitor displays the connection status with the external device. ・Lit in light blue: Communicating with external device ⑦Network monitor ・OFF: Communication with external device is disconnected Used to update the software version or renew the license key with a USB ⑧USB connector...
-
Page 11: Installation
TW-800R-SLNX 5.Installation ① Install the receiver in a location where it can be seen well from the transmitter and can receive radio waves stably. Install the receiver so that the side with various setting keys is facing the operator. ② Connect the AC adapter plug to the power jack. - Page 12 TW-800R-SLNX ④ To link the receiver to an external device, connect the LAN cable between them. ⚫ Connect the LAN connector of the receiver to the switching hub or the PC’s LAN connector with the LAN cable. LAN cable ⚫...
-
Page 13: Setting Method
TW-800R-SLNX 6.Setting Method 6-1.Pairing (Registration) The transmitter and the receiver need to be paired before use. By pairing the receiver and transmitter, they recognize an identification signal from each other and communicate with each other. The receiver can be paired with up to two transmitters. -
Page 14: Error Indication On Pairing
TW-800R-SLNX 6-1-2. Error indication on pairing When the receive (RX) indicator is lit (green), it means that no transmitter has been paired. Please perform pairing. 6-1-3. Reset pairing Unpair ID1 and ID2 from the receiver. ① Press the [Power key] while pressing and holding the [Setting key] of the receiver. The Receiver (RX) LED blinks in green and the receiver enters the pairing mode for 10 seconds. -
Page 15: Settings With Web Server
TW-800R-SLNX 6-3. Settings With Web Server The following items can be viewed or changed by using the Web server functions of the receiver. Item Contents System Information Viewing the model number, firmware version, serial number and MAC address. Device Setup... -
Page 16: Setting Account
TW-800R-SLNX After log in, the system information screen is displayed. The screen is divided into two parts, left and right. The menu is displayed on the left. System Information Menu Item Example Model Name TW-800R-SL2 Version (Firmware version) 1.00 Serial No. -
Page 17: Setting Network Information
TW-800R-SLNX 6-3-3. Setting network information Click “Network Setup” in the Menu. Change the necessary items and click the [Submit] button. *For details of the settings, contact the network administrator. Network Setup Item Entry example IP Address 192.168.3.102 (Default) Subnet Mask 255.255.255.0 (Default) - Page 18 TW-800R-SLNX Reg-ID List (Registered transmitter ID) The paired transmitter IDs are displayed. *Transmitter ID is a 10-digit serial number shown on the label attached to the transmitter. When pairing is not done, “0000000000” is displayed. Device Setup ⚫ [Output 1/ Output 2] Output condition setting For external outputs, use the supplied “External output cable TW-SCLO-4”.
- Page 19 TW-800R-SLNX ⚫ [Double count protect time] Double count prevention time setting The receiver can disable the signal from the same transmitter for a period of time after receiving the signal from the transmitter. This time is called the double count prevention time.
- Page 20 TW-800R-SLNX [Data length type] Ethernet output data type setting ⚫ The data size varies depending on the set values. For details of each data format, refer to “7-2.Communication specifications” described later. Setting value Contents Short Generates short data. (Data size: 19byte) Long Generates long data.
-
Page 21: Ethernet Communication
TW-800R-SLNX 7.Ethernet Communication The receiver acts as a socket server and communicate with up to 10 clients. When connections with clients are established, the network monitor lights up (light blue). The unlit state of the network monitor indicates the receiver is not connected with clients. -
Page 22: 7-2.Communication Specification
TW-800R-SLNX 7-2.Communication Specification Ethernet Interface Interface RJ-45 Ethernet 10BASE-T or 100BASE-T, Duplex full or half Compatibility Ethernet Version 2.0 / IEEE802.3 Protocol TCP/IP, UDP/IP Ethernet output data types are classified into two types: “Short data” and “Long data”. Set a data type with a Web server function. ([Device Setup] – “Data length Type”) Long Data is short data added by extension region of 24bytes (Transmitter-specific data, etc.). - Page 23 TW-800R-SLNX ◆ Formatting long data (43byte) Fastening Data information varied according Maintenance Transmitter Transmitter Preamble STX test switch ETX Checksum to the type ID number Data Data battery information transmitter used Byte Data name Description Preamble FFH,FFH,FFH ID number 10 digit is converted to ASCII data(Hexadecimal).
-
Page 24: How To Use
TW-800R-SLNX 8.How to Use 8-1. Starting a Task with a Tool ① Make sure Receiver (RX) LED is not lit. When Receiver (RX) LED lights up(green), this indicates the receiver is not paired with a transmitter. Perform pairing. For the pairing procedure, refer to "6-1-1. Pairing procedure". -
Page 25: Battery Replacement Notification Function
TW-800R-SLNX 8-3. Battery replacement notification function The battery level notification function notifies the battery level status in two stages. ①Notification of low battery level with test switch: It is possible to check the battery level with the test switch.When the battery is low, the red LED will light for 1 second. -
Page 26: Specifications
TW-800R-SLNX 9.Specifications Item Specifications 2.4GHz Low Power Data Communication System Radio Equipment of Certification Regulation Article 2, Paragraph 1 Item 19 Compliance Standards Radio Equipment Regulations Article 20 of 49 Paragraph 1 Radio format 2,403MHz-2,478MHz Frequency Band 76CH Number of Channels... -
Page 27: Dimensions Drawing
TW-800R-SLNX ■Dimensions Drawing Receiver TW-800R-SLNX... - Page 28 TW-800R-SLNX Options ⚫ Wall mounting bracket TW-SCLF01 ⚫ TW-800R-SLNX Drawing with TW-SCLF01 installed...
- Page 29 TW-800R-SLNX ⚫ Desktop Stand TW-SCDS01...
-
Page 30: Troubleshooting
TW-800R-SLNX ■Troubleshooting Phenomenon Cause and remedy The power of the receiver is not ON. No LED lights up →Make sure the power of the receiver to communicate with the transmitter is ON. Pairing is not done. (not registered) The receiver does not receive a signal from →Perform pairing with the receiver to communicate with the... -
Page 31: After Service And Warranty
TW-800R-SLNX ■After service and Warranty If the problem persists even after a remedy action is taken or if it is unclear which remedy action should be taken, then contact the dealer where the product was purchased or our Sales Department with the following information: Product name / Serial No. - Page 32 HERUTU ELECTRONICS CORPORATION 422-1 Higashimikata-cho, Kita-ku, Hamamatsu, Shizuoka, 433-8104 Japan (Sales dept) TEL.+81-53-438-3555 FAX. +81-53-438-3411 Website URL https://www.herutu.co.jp/en/ E-mail info@herutu.co.jp...
