Page 1: Table Of Contents
Wireless Communication TW-800R-EXS Manual V1.10 Contents Please use this operation manual correctly on reading ■General outline ............1 well. Please keep it carefully to be able to read ■Main part and accessories ........2 immediately, when required. ■Safety concerns ............. 4 ■Specification ............ -
Page 3: General Outline
TW-800-EXS ■General outline [TW-800R-EXS] is a product to be fixed expansion unit of RS232C output to [TW-800R]. This manual is described about only a function of expansion unit. Please read [TW-800 manual] about transmitter [TW-800T] and receiver [TW-800R] and wireless specification. -
Page 4: Main Part And Accessories
TW-800-EXS ■Main part and accessories Receiver TW-800R-EXS TW-800R-EXS ×1 (Dipole antenna for ANT2 is set at shipment) ※ANT2 is fixed by resin before shipment by regulation of FCC/IC in an applicable country. Onerous option ・AC Adapter ADB24050-C(With connecting cable 1.8m) Cable approx 1.5m... - Page 5 TW-800-EXS ・External antenna MB-13F(With magnet base/Coaxial cable approx 1.5m) Antenna approx 22.5cm Coaxial cable approx 1.5m ※ANT2 is fixed by resin before shipment by regulation of FCC/IC in an applicable country. ・RS-232C Cable(Straight) 6232-9F9F-06(approx 1.8m) D-sub 9 pin(Female) <=> D-sub 9 pin(Female)
-
Page 6: Safety Concerns
TW-800-EXS ■Safety concerns Safety concerns (Be sure to read) To prevent human injury of user or damage in property from occurring, be sure to observe the precautions shown below. ■ The degree in safety hazard and damage generated by the wrong usage while ignoring the descriptions is classified by the following displays. -
Page 7: Specification
TW-800-EXS ■Specification ●Receiver TW-800R-EXS Items Specification Interface RS-232C*1 Contact output* 1point (Terminal block:M3(2P)) Contact mechanism MOS-FET/1a Output Rated load voltage AC/DC30V per point Rated load current 0.5A per point Buzzer Piezoelectric Buzzer 95dB/m LED for receiving(Green) * 1point (Combination lighting switch for pairing) -
Page 8: Communication
TW-800-EXS ■Communication Connector It is used D-sub 9 pin (Male) connector. Screw for fixed: Inch screw #4-40 Pin specification (For DCE) Pin No. Signal Name Reference Career No using Data output Data transmission(Receiver->connecting equipment) Data receiving(connecting equipment->Receiver) Data input *No using Data terminal ready No using Signal ground... - Page 9 TW-800-EXS Communication Specification ・RS-232C protocol Items Contents Baud rate 19200bps/38400bps Parity None Data length 8 bit Stop bit 1 bit Flow sequence RTS CTS/none Data format Transmitter Tightening information Check Preamble ID number Test switch information Data name Explanation Byte Preamble FFH,FFH,FFH ID number 10 digit is converted to ASCII data(Hexadecimal)
-
Page 10: Name And Function Of Each Part
TW-800-EXS ■Name and function of each part ●Receiver TW-800R-EXS This label is added For FCC/IC. 1.Power switch For power ON and OFF 2.Terminal block of Terminal block for power source of DC24V(M3) power source 3.DIP Switch1 DIP switch for setting (6 selection) 4.DIP Switch2... -
Page 11: Setting
TW-800-EXS ■Setting It needs doing “pairing” a transmitter and a receiver before using. The number of transmitters which can register pairing to one set of a receiver does not have restriction. ID number of receiver is memorized in transmitter. Transmitter transmits the signal included ID number of receiver. Receiver can receive the signal attached ID number itself. - Page 12 TW-800-EXS ●Setting of receiver You can set “relay output time”, “Double count protect time”, “Behavior of buzzer” by six dipswitch. Please set by your operation. DIP SWITCH1(Main body side) ◆Buzzer ON/OFF DIPSW Buzzer does not sound Buzzer sounds ◆Relay output time (4 kinds) DIPSW 50ms 200ms...
- Page 13 TW-800-EXS DIP SWITCH2(Expansion unit side) ◆Baud rate setting DIP SW 38400bps 19200bps ◆Flow control DIP SW Flow control no using Flow control(RTS/CTS) using *DIP SWITCH2 3-6 is not used. ◆Caution ・When the signal from another transmitter is received while the receiver was carrying out the relay output, the relay output for transmitters received later is not performed.
-
Page 14: How To Use
TW-800-EXS ■How to use 1. Power switch of receiver is turned on. Please confirm the LED situation as turning off. When the LED for receiving turns on, the transmitter is not registered by pairing. Please make a pairing with transmitter. LED for receiving (Green) (Lighting switch for pairing) LED(Green &... - Page 15 TW-800-EXS ●TEST SWITCH There is a test switch for checking the battery and communication. When the transmitter transmit the signal by test switch not limit switch, receiver doesn’t output relay output. But LED of receiver only turns on. Also transmitter make a checking the battery at pushing the test switch. You can know the battery situation by transmitter LED and Receiver LED TEST SWITCH is combination with Pairing switch.
-
Page 16: Note On Use
TW-800-EXS ■Note on use ■Caution for wireless Law ○Radio device in this product has been certified by the Radio Law. It does not needs a license of radio stations according to using this product. ○Do not use it close to a person with a cardiac pacemaker. Electromagnetic interference may affect it, putting his/her life at risk. -
Page 17: Dimensional Drawing
TW-800-EXS ■Dimensional drawing ●Receiver TW-800R-EXS... -
Page 18: After Service And Warranty
TW-800-EXS ■After service and Warranty If something is wrong.If you should find anything wrong with the machine when using it under normal conditions, check the following items and contact the outlet store through which you purchased the product or our Sales Office. - Page 19 TW-800-EXS (1) Switches (limit switches, pushbutton switches, or the like) (2) Battery cells or batteries (dry batteries, button batteries, or the like) (3) Other items subject to consumption or limitation of life caused by use. 8. Troubles occurring due to handling against the use instructions or precautions specified in this operation manual.
- Page 20 HERUTU ELECTRONICS CORPORATION 〒433-8103 62-1Toyooka-cho, Kita-ku, Hamamatsu-shi, Shizuoka-ken （Sales dept）TEL.+81-053- 438－3555 FAX. +81-53- 438－3411 http://www.herutu.co.jp E-mail webmaster@herutu.co.jp...
