2-34 Maintenance principles
Nodes
DMS VoiceMail supports up to 16 nodes that are numbered 1 to 16. In the
hardware database, the HWLOC for node one is n-1 and for node two is n-2,
where "n" is the frame number of the SPM. A node refers to one processor
card and its transition module and any associated peripheral cards and their
transition modules.
Frequently, SEERs indicate a TaskID or node number. Every program has a
16-digit TaskID. The first eight digits indicate which node the program runs
on.
Table 2-1 specifies the node number, the location of the 68K or 68KU card
in the SPM, the first eight digits of the program TaskID, and the node type.
Table 2-1xxx
HWLOC node information
Node
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
297-7001-503 Standard 02.02 March 1994
Position of
68K Card First 8 digits of
Shelf - Slot Program TaskID
Lower 8 01000000
Lower 12 05000000
Lower 30 17000000
Lower 29 16000000
Lower 19 0C000000
Lower 16 09000000
Upper 30 37000000
Upper 29 36000000
Upper 19 2C000000
Upper 15 28000000
Reserved for future use
Reserved for future use
Lower 25 12000000
Lower 22 0D000000
Upper 25 32000000
Upper 22 2D000000
Node Type
MSP
MSP
SPN
SPN
SPN
SPN
SPN
SPN
SPN
SPN
TIFN
TIFN
TIFN
TIFN
