Carmen Kitchen Chair
Assembly Instructions
Dimensions
Width - 42.8cm
Depth - 44.7cm
Height - 78cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
239/2091
226/2657
Issue 1 - 6/03/14
Advertisement
Related Manuals for Argos Carmen 239/2091
Summary of Contents for Argos Carmen 239/2091
- Page 1 Width - 42.8cm Depth - 44.7cm Height - 78cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Issue 1 - 6/03/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • During assembly do not stand • To reduce • Check you have all the components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below The quantities below are for 4 chairs Front leg x 4 Back leg x 4 Back rest x 4 (42.8 x 35.6cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly of 4 chairs. In some cases more fittings may be supplied than are required. 30mm Bolt x 12 44mm Bolt x 16 47mm Bolt x 8 Nut x 8...
- Page 5 Assembly Instructions Step 1 Assemble legs Attach front leg back leg using bolts , large plain washers and nuts as shown Note: Do not fully tighten bolts. Step 2 Assembly will be easier with 2 people. Assemble backrest to the chair frame using bolts , curved washers and T-nuts g .
-
Page 6: Customer Helpline
Note: Re-tighten all the bolts. Turn the chair upright. Assembly is complete. Customer Helpline: If you need help or have damaged or missing parts, call the Argos = 0345 6400800...
