DESCRIPTION
Steel structure
Powder coated
The time to make the assembly of this volleyball post is estimated for 1 person, at 20minutes. (without sealing).
The equipement has to be regularly maintained by the owner. It is adviced to:
- Check every week that all the screws are correctly tightened
- Fix paint defects if the module has been damaged, using the adapted paint, specified by the manufacturer.
- Replace all damaged or missing parts with a spare part recommended by the manufacturer.
- Clean the product by using dishwasher soap, clean water, and soft cloth
It is advised to carry out this cleaning once or twice a year, or even more regularly according to the environmental
conditions (saline environment, ...).
One full year parts and labor guarantee. Every claim regarding condition of the delivered equipment has to be done
within the legal period of the reception of the material. The warranty will not apply to:
-
all degradation during the transport.
-
all degradation due to use differing from which was intended.
-
all degradation due to poor maintenance.
-
any defect claimed after the end of the legal period.
-
any damaged due to a faulty installation and assembly of the module
Assembly INSTRUCTIONS
MOBILE STORAGE RACKS FOR 4
PRODUCT REF
ASSEMBLY TIME
MAINTENANCE
WARRANTY
PAIRS OF POSTS
S30454
:
.
UNIT
1 1
Advertisement
Table of Contents
Related Manuals for Sodex Sport S30454
Summary of Contents for Sodex Sport S30454
- Page 1 ASSEMBLY INSTRUCTIONS MOBILE STORAGE RACKS FOR 4 PAIRS OF POSTS S30454 UNIT PRODUCT REF DESCRIPTION Steel structure Powder coated ASSEMBLY TIME The time to make the assembly of this volleyball post is estimated for 1 person, at 20minutes. (without sealing).
- Page 2 ASSEMBLY NECESSARY TOOLS (NOT INCLUDED) Wrench 17mm Wrench 19mm Screwer INCLUDED TEMS 1– ASSEMBLY OF THE FRAME (x2) LEFT FRAME Repeat this step with the right side frame Wheel + SS Washers 12+ LOWER CONNECTING SS Nuts M12 Snap the 2 lower connecting bars to the left frame until the holes are aligned. Then tighten by putting the wheel axle D70 in this hole.
- Page 3 ASSEMBLY 2– ASSEMBLY OF THE FRAME TO THE CONNECTING BAR (x2) SS Screws M10x70 + SS Washers 10 + CONNECTING BAR LEFT FRAME Repeat this step with the right side frame NECESSARY ITEMS 3– ASSEMBLY OF THE WOOD FLOOR WOOD FLOOR Self tapping screws M5x15 NECESSARY ITEMS...
- Page 4 PACKING LIST MOBILE STORAGE RACKS FOR 4 PAIRS OF POSTS PRODUCT REF S30454 Index C UNIT NOMENCLATURE Package Weight Dim. Index Designation Description Quantity Packing Method N° (kg) (mm) Plastic bubbles S30454-01 Left side + right side + cardboard 5...
