Sodex Sport S30426 Product Sheet

Volleyball referee stand

Download this manual

DESCRIPTION

Aluminium Structure

Powder coated

CONFORM

The time to make the assembly of this product is estimated for 2 persons, at 25 minutes

The equipement has to be regularly maintained by the owner. It is adviced to:

- Check every week that all the screws are correctly tightened

- Fix paint defects if the module has been damaged, using the adapted paint, specified by the

manufacturer.

- Replace all damaged or missing parts with a spare part recommended by the manufacturer.

- Clean the product by using dishwasher soap, clean water, and soft cloth.

One full year parts and labor guarantee. Every claim regarding condition of the delivered equipment has

to be done within the legal period of the reception of the material. The warranty will not apply to:

All degradation during the transport.

All degradation due to use differing from which was intended.

All degradation due to poor maintenance.

Any defect claimed after the end of the legal period.

Any damaged due to a faulty installation and assembly of the module

VOLLEYBALL REFEREE STAND

PRODUCT REF

ASSEMBLY TIME

MAINTENANCE

WARRANTY

PRODUCT SHEET

S30426

UNIT

Need help?

Do you have a question about the S30426 and is the answer not in the manual?

Page 1 PRODUCT SHEET VOLLEYBALL REFEREE STAND S30426 UNIT PRODUCT REF DESCRIPTION Aluminium Structure Powder coated CONFORM ASSEMBLY TIME The time to make the assembly of this product is estimated for 2 persons, at 25 minutes MAINTENANCE The equipement has to be regularly maintained by the owner. It is adviced to:...
Page 2: Included Items
ASSEMBLY NECESSARY TOOLS (NOT INCLUDED) Screwdriver Wrench 10mm Wrench 13mm INCLUDED ITEMS 1– ASSEMBLY OF THE REINFORCING BARS (x6) Screws EZ M8x20 + Washers EZ 8 + Nuts EZ M8 Reinforced bars NECESSARY ITEMS...
Page 3 ASSEMBLY 2- ASSEMBLY OF THE STEP BARS (x6) Screws EZ M8x20 + Washers EZ 8 + Nuts EZ M8 Step bars Do not tighten when assemble screws. NECESSARY ITEMS 3- ASSEMBLY OF THE STAND Screws EZ M8x60+ Washers EZ M8+ Nuts EZ M8 Support bar NECESSARY...
Page 4 ASSEMBLY 4 - ASSEMBLY OF THE SEAT Screws EZ M6x50 + Nuts Lock EZ M6 NECESSARY ITEMS 5 - ASSEMBLY OF THE DESK...
Page 5 PACKING LIST VOLLEYBALL REFEREE STAND PRODUCT REF S30426 Index D UNIT NOMENCLATURE Package Weight Dim. Index Designation Description Quantity Packing Method N° (kg) (mm) S30426-01 Frame left+right 1 + 1 S30426-03 Climbing bar No 1 S30426-03 Climbing bar No 2...
Page 6: Packing List
PACKING LIST VOLLEYBALL REFEREE STAND PRODUCT REF S30426 Index D UNIT PRE-ASSEMBLED ACCESSORIES Package Designation Description Note N° Assemble on left & NC34 Rubber cap D34 right frame Assemble on left & NNT34 PVC cap D34 right frame CSN34 PVC clip D34...
