- Page 1 Instruction Manual PLT200 - POCKET LASER TACH 200 Tachometer/Rate Meter/Totalizer/Timer 15 Columbia Drive Amherst, NH 03031 USA Phone: (603) 883-3390 • Fax: (603) 886-3300 E-mail: support@monarchinstrument.com Website: www.monarchinstrument.com...
- Page 2 [160 m] away. Can be a distraction up to 1 mile [1.6 km] away. NEVER point any laser towards aircraft or vehicles; it is unsafe and illegal. Manufacturer: Safe Use Guidance: Monarch Instrument Class 2 lasers are considered safe 15 Columbia Drive for accidental eye exposure. Do Amherst, NH 03031 USA not look or stare into beam.
-
Page 3: Table Of Contents
10.2 TIMER Operation ............ 18 11.0 BATTERIES ..............19 12.0 SPECIFICATIONS ............20 13.0 CLEANING ..............24 14.0 SENSORS AND ACCESSORIES ........24 Monarch Instrument’s Limited Warranty applies. www.monarchinstrument.com for details. Warranty Registration and Extended Warranty Coverage information is available online at www.monarchinstrument.com. -
Page 4: Description
DESCRIPTION The Pocket Laser Tach 200 is a multifunction tachometer, ratemeter, totalizer and timer. It is programmable to read in English or metric units. An input socket accepts remote sensing devices and an output socket allows for pulse output to external indicating devices. The PLT200 can be tripod mounted and locked-on for accurate and continuous operation. -
Page 5: Lcd Symbols
LCD SYMBOLS On-Target Indicator — blinks whenever there is an input signal and will appear to be solid on at higher frequencies Low Battery icon — indicates that the batteries are low and need to be replaced. Times Ten icon — indicates that the value shown is ten times that which is displayed Laser Indicator —... -
Page 6: Input/Output
INPUT/OUTPUT Input: Accepts remote sensor or Remote Contact Assembly (RCA) 1/8" [3.5 mm] stereo phone plug Output: 1 pulse per revolution TTL output on internal operation; pulse repeater with external sensors 1/8" [3.5 mm] mono phone plug Input socket (▲) Output socket (▼) Common (GND) -
Page 7: Preparation For Measurement
PREPARATION FOR MEASUREMENT Noncontact Preparation Follow the steps below for internal operation (red laser) or external operation using optional Remote Optical Sensor (ROS-Red LED): 2. Apply 1/2" square 1. Clean shaft. of T-5 Reflective tape. For small shafts: As small as 1/8" wide on side or radius edge Direct Contact Preparation Follow external operation ONLY using optional Remote Contact... -
Page 8: Connecting External Sensors
Connecting External Sensors Plug sensor into Input socket Remote Contact Assembly (RCA) (shown with optional 12-inch Wheel) Remote Optical Infrared Sensor Magnetic Sensor Sensor (ROS-P) (IRS-P) with Amplifier (MT-190P) Please visit www.monarchinstrument.com for additional sensor options. -
Page 9: Taking Measurements
TAKING MEASUREMENTS Noncontact Measurements Handheld External Sensor (ROS shown) Light Laser Direct Contact Measurements Rotational Linear Note: Use concave tip for small shafts. to RCA from PLT200 from PLT200 ONLY USE MODERATE PRESSURE WARNING: Making measurements in direct contact with rotating equipment can be dangerous. -
Page 10: Tachometer Mode
7.0 TACHometer MODE A tachometer measures speed or linear rate with respect to time; time intervals are seconds, minutes, or hours. Rotational speed can be measured in Revolutions (Revs) per second, per minute, or per hour. The most common measurement is RPM or Revs per minute using the optical Tachometer Mode. - Page 11 6. Enter selection RPS, RPM or RPH of Units 7. Select Units Repeat until desired Units displayed 8. Save and advance 9. Enter selection NONE,1, 2 or 3 of number of decimal places 10. Select decimal Repeat until desired decimal places places displayed 11.
-
Page 12: Tachometer Operation
TACHometer Operation Measure Press and hold Lock On Recall Max Max speed Recall Min Min speed If unit Lock On Resets Max/Min Power OFF Automatic after 90 seconds if unit not Locked On RATE MODE Measurement of units in addition to Revs requires the attachment of the Remote Contact Assembly and tips/wheels. -
Page 13: Rate Setup
RATE Setup 1. Turn EXTRN , then scrolling message, then last Power ON Units selected 1a. To toggle Lock On/Off Press and hold Lock On 2. Enter Setup 3. Enter Last mode selected is selection displayed of Mode Toggles between 4. - Page 14 RATE Setup (continued): 7. Select Units Repeat until desired Units displayed 8. Save and advance Rotational Units Linear Units Only for Linear Units: 8a. Enter selection Last wheel of Wheel selected is displayed 8b. Select Toggles Wheel between 10CM and 12IN 8c.
-
Page 15: Rate Operation
12. Exit Setup – DONE, USE CONTACT T ready to or [Wheel selected], measure then Units selected The unit will remember these settings (including Lock On/Off) even if turned off then back on. RATE Operation Measure Press and hold Lock On Recall Max Max Speed Recall Min... -
Page 16: Totalizer Mode
9.0 TOTALIZER MODE Totalizer accumulates input on an ongoing basis. In the simplest form the unit acts as an optical counter, incrementing the display each time an input pulse is sensed. Using the Remote Contact Assembly with various tips and wheels, the unit can totalize in revs, inches, feet, yards, centimeters, and meters. - Page 17 5. Save and advance Different options displayed for 6. Enter Internal or External operation selection of Units Internal or External ROS: External Remote Contact Assembly: Rotational: REV COUNT Only Linear: INCH, FEET, YARDS, CM, METER 7. Select Units Repeat until desired Units displayed 8.
- Page 18 TOTALizer Setup (continued): 9. Enter selection NONE, 1, 2 or 3 of number of decimal places 10. Select decimal Repeat until desired decimal places places displayed 11. Save and advance 12. Exit Setup - ready to measure Units = COUNT: Rotational/Linear Units: DONE, DONE,...
-
Page 19: Totalizer Operation
TOTALizer Operation Measure Press and hold Lock On Recall Max Max or Min Speed (in or Min last selected Tach or Rate mode units) Recall Time Shows time in seconds in seconds from when the Start/ Reset button is pressed until the last input signal measured If unit is... -
Page 20: Timer Mode
10.0 TIMER MODE Accumulates time in minutes, seconds, and tenths of a second. There are two modes of operation. The Manual mode operates like a stopwatch, the timing period being started and stopped by the user. The Auto mode can be stopped and started by the user or a piece of reflective tape on objects. -
Page 21: Timer Operation
6. Enter selection MAN or AUTO of Timer function Toggles between 7. Select Timer Manual and function Auto 8. Save and advance DONE , then Units 9. Exit Setup – selected ready to measure Unit will remember these settings (including lock on/off) even if turned off and back on. -
Page 22: Batteries
TIMER Operation (continued): With Timer running - stops at elapsed time to date; to continue, press again If Timer stopped - Power Off automatic after 90 seconds if unit not Locked On Automatic after 99:59.9 11.0 BATTERIES When displayed, replace batteries Remove battery cover Install two 1.5 V... -
Page 23: Specifications
12.0 SPECIFICATIONS Specifications* PLT200 Pocket Laser Tachometer Laser Specifications: Class 2 (per IEC 60825-1:2014) This product complies with IEC60825-1 Ed.3 and Classification 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50 of June 2007 Max Laser Output <... - Page 24 Specifications* PLT200 Pocket Laser Tachometer Contact Specifications (continued): Resolution - Fixed 1 (10 above 99,999) Resolution - Autoranging 0.001 to 1.0 (10 above 99,999) ±0.05% of reading (RPM) or resolution limit Accuracy - Revs (with no slippage) ±0.5% of reading or resolution limit Accuracy - Linear (with no slippage) Contact Measurement Ranges:...
- Page 25 Specifications* PLT200 Pocket Laser Tachometer Rates (continued): Wheel Circumferences 10 cm: 0.055 to 2,187.2 Yards per Minute 12 in.: 0.167 to 4,000.0 10 cm: 3.281 to 131,233 Yards per Hour 12 in.: 10.000 to 240,000 10 cm: 0.002 to 74.564 Miles per Hour 12 in.: 0.006 to 136.36 10 cm: 0.084 to 3,333.3...
- Page 26 Specifications* PLT200 Pocket Laser Tachometer Dual LCD: 5-digit upper/scrolling and 5-digit Display alphanumeric lower display Two (2) AA 1.5 V … (DC) alkaline included Batteries (Note: Batteries are NOT rechargeable.) 30 hours continuous typical with Battery Life batteries provided External Input: Absolute Max -0.3 V to 5 V …...
-
Page 27: Cleaning
13.0 CLEANING To clean the instrument, wipe with a damp cloth using mild, soapy water. 14.0 SENSORS AND ACCESSORIES See webpage for the complete list of accessories. Sensors: RLS-P PN: 6180-081 Rugged Laser Sensor with removable 3 m cable, M12 connector to 1/8" phone plug connector ROLS-P PN: 6180-029 Remote Optical Laser Sensor with 8 ft. - Page 28 THE PROFESSIONAL’S CHOICE Monarch Instrument is committed to excellence and quality in manufacturing, sales, and service. ™ Track-It Data Loggers Panel Tachometers Portable Tachometers Frequency Portable Strobes Fixed Mounted Converters Strobes ™ Speed Sensors DataChart Paperless Recorders 15 Columbia Drive, Amherst NH 03031 USA Tel.: (603) 883-3390 // Fax: (603) 886-3390...
