Configuring BSL_336

6.4 #ShowCfg - Show Configuration

6.5 #EraseCfg - Erase Config

14:04:30.624 MonitorFSM00,st01: NvRAM_Init: No valid Config present
14:04:30.632 MonitorFSM00,st01: NvRAM_Init: Empty config RAM memory
14:04:30.640 NvRAM_Driv00,st04: Start burning EEPROM (area=001B, size=0256)
14:04:30.649 NvRAM_Driv00,st05: NvRAM: Config OK
Burn EEPROM addr 0x21 with 30
...(many "burn" lines)..
14:04:30.818 NvRAM_Driv00,st02: Finished burning EEPROM

6.6 #CfgBaud - Set Baud Rates

Interfacing Voyage Data Recorder Systems, AutroSafe Interactive Fire-Alarm System, 116-P-BSL336/EE, RevA 2007-01-25,
The current configuration can be inspected by typing:
#ShowCfg↵
== Table: Settings. #lines=1
Line: 1
AutroComBaud: 19200
VDR_Baud
AlivePeriod :
StatusPeriod:
To load default values type:
#EraseCfg↵
If you change the baud rate, the BSL-336 software must be restarted;
this can be done by typing the command #rt or pressing the RESET
button on BSL-336.
The baud rates on both sides of BSL-336 can be modified.
•
Parameter 1:
The AutroCom baud rate is, by default, 19200, but may be
set to 9600.
•
Parameter 2:
The VDR baud rate is, by default, 38400 (newer VDRs), but
for older VDRs can use 4800). A higher baud rate gives better
performance for fire-detection systems with more than 100
detectors.
The commands
#CfgBaud19200:38400↵
#CfgBaud19200:4800↵
The baud rates can be set to any value, independently.
If you change the baud rate, the BSL-336 software must be restarted;
this can be done by typing the command #rt or pressing the RESET
button on BSL-336.
Autronica Fire and Security AS
Page 22
: 38400
4
120
new version
old version
