Siemens SIMATIC NET RUGGEDCOM RSG907R Installation Manual page 52

61000-4-9
61000-4-11
61000-4-16
61000-4-17
61000-4-18
61000-4-29
60255-27
EMC Immunity Type Tests per IEEE 1613
Note
The RUGGEDCOM RSG907R meets Class 2 requirements for an all-fiber
configuration and Class 1 requirements for copper ports. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
RUGGEDCOM RSG907R
Installation Manual, 02/2021, C79000-G8976-1387-12
Test
IEC Pulse Magnetic Field
IEC Voltage Dips and Interrupts
IEC Mains Frequency Voltage
IEC Ripple on DC Power Supply
IEC Damped Oscillatory Wave
IEC Voltage Dips and Interrupts
IEC Dielectric Strength
HV Impulse
Test
IEEE 1613
IEEE 1613
IEEE 1613
6.2 EMC and Environmental Type Tests
Description
Enclosure
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
DC Power
Ports
Slow
Damped
DC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Description
ESD Enclosure Contact
Enclosure Air
Radiated RFI Enclosure Ports
Fast Signal Ports
Transient
DC Power Ports
AC Power Ports
Earth Ground Ports
Test Levels
300 A/m
30% for 0.5 Cycles
60% for 5 Cycles
100% for 250 Cycles
30 V Continuous
300 V for 1 s
30 V Continuous
300 V for 1 s
15%
2.5 kV Common
100 kHz or 1 MHz
30% for 0.1 s
60% for 0.1 s
100% for 0.05 s
2 kV (Failsafe Relay Output)
2 kV or 2.8kV DC
2 kV
5 kV (Failsafe Relay Output)
5 kV
5 kV
Test Levels
± 8 kV
± 15 kV
35 V/m
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV
Certification
Severity
Levels
4
4
4
4
3
43
