7

Operations on PC

10-bit Gamma Adjustment
The 10-bit input source supports 10-bit gamma adjustment.
Step 1 Run NovaLCT. On the menu bar, choose User > Advanced Synchronous System User Login. Enter the
password and click Login.
Step 2 Click Screen Configuration, choose a communication port and click Next.
Step 3 On the Sending Card tab page, set the input source bit depth to 10bit and click Set.
Step 4 On the NovaLCT main window, choose Brightness > Manual Adjustment.
Step 5 Under Advanced Settings, choose Gamma Adjustment > Gamma Value Adjustment.
Step 6 Drag the slider to adjust the value and then click Save to HW.
Figure 7-1 10-bit gamma adjustment
Input Source Bit Depth
Set the input source bit depth to 8bit, 10bit or 12bit.
Step 1 Run NovaLCT. On the menu bar, choose User > Advanced Synchronous System User Login. Enter the
password and click Login.
Step 2 Click Screen Configuration, choose a communication port and click Next.
Step 3 Next to Input Source Bit Depth on the Sending Card tab page, select an option.
Step 4 Click Save System Configuration File and Save.
