Page 9: General Introduction
TABLET The main unit of the PS70PRO is the tablet, which has a built-in VCI module, which can be directly connected to the tablet and the car with the main test line, without the need to connect to an... -
Page 10: Front View Of Tablet
FRONT VIEW OF TABLET Fig 1-1 Sample of Tablet Front View The front of the main unit is a touchable display screen, you can use your fingers to operate on the screen to complete the car diagnosis. BACK VIEW OF TABLET ①... -
Page 11: Host Ports
The product model and S/N are laser-engraved on the back of the display tablet, and the small hole at the bottom is the Loudspeaker. Nameplate: Display basic information such as S/N and model etc. Loudspeaker: external sound can be played, supporting the playback of music, etc. -
Page 12: Technical Specifications
TECHNICAL SPECIFICATIONS Table 1-1 Specification Item Description Operating System Android Processor Quad-core 1.6GHz Processor Memory 32GB 7.0-inch touch screen with 1024×600 Display resolution Connectivity Wi-Fi Sensors Gravity sensor, light sensor Auto Input/Output Microphone, speaker Power and Battery 4000mAh, 3.7V lithium-polymer battery Power Voltage Power Consumption Operating... -
Page 13: Package Kit
PACKAGE KIT MAIN UNIT Tablet 1 pcs OTHER ACCESSORIES OBDⅡ-16 Connector (1 pcs) * Used to connect the main cable and the car. Main Test Cable (1 pcs) *The main cable is used to connect the Tablet to the connector. USB Cable(1 pcs) ... -
Page 14: Getting Started
ETTING TARTED ACTIVATION After first-time users press and hold the power button to turn on the system, the system will automatically enter the guide process and request to select the language for the operating system. Fig 2-1 Select Language before Activation After setting the system language, you will enter the activation page, as shown in the figure below. - Page 15 Fig 2-2 Sample of Start Activate Click Start Activate to enter the activation page, as shown below: Fig 2-3 Input your Email Address in the Field...
- Page 16 A pop-up window showing Activation Success indicates that you have completed the first boot setup, click OK to enter the diagnostic system and start using the device. Fig 2-4 Sample of Activation Success...
-
Page 17: Main Interface
MAIN INTERFACE OPERATION SYSTEM As shown in the figure below, this interface is the main page of the operating system of the device. You can also return to this interface at any time by clicking 【⚪ 】on the bottom navigation bar. - Page 18 File Explorer Settings for Android System Browser: Click on the browser icon to enter the browser to view the official website of XTOOL or search for other information. Gallery: Click the Gallery icon to enter the album to quickly view the pictures or screenshots stored in the device.
-
Page 19: Diagnosis System Entrance
Fig 2-6 Sample of Application Square ES File Explorer: You can manage APP, music, files, pictures, etc. in the device in this function, and you can also use Local/Home/Cleaner to clean up files. DIAGNOSIS SYSTEM ENTRANCE Once activated, you will automatically enter the diagnostic system with the following main screen. - Page 20 Fig 2-7 Sample of Smart Diagnosis System Homepage The main interface is mainly composed of Function Buttons and Navigation Buttons. The touch screen navigation is menu-driven, and you can quickly access functions by clicking on the option title and answering the dialogue window. A detailed description of the menu structure can be found in the next section Function Buttons.
-
Page 21: Function Buttons
FUNCTION BUTTONS The following table briefly describes each function button Table 2-2 Item Description Quickly access to the vehicle system to identify the vehicle VIN code Enter to select a vehicle Includes special functions for car diagnosis You can view the vehicle diagnostic report In case of failure, you can control the diagnostic equipment remotely Users can upgrade the available software with... -
Page 22: Navigation Buttons
NAVIGATION BUTTONS Instructions for operating the navigation bar buttons at the bottom of the screen, as described in the table below: Table 2-3 Items Descriptions Back to the previous interface Back to the main interface of the Android system Shows recently used applications Press for screenshot Increase volume Display bluetooth statu... -
Page 23: Notification Bar
NOTIFICATION BAR Slide down to open the notification bar. Users can adjust the brightness of the screen when they need it, and you can also connect Wi-Fi and so on. Fig 2-8 Sample of NOTIFICATION BAR... -
Page 24: Update
PDATE After activating the device, please update the software in "Update" first. The device will pull all currently supported software packages, and you can download them as needed. ALL software updates directly via the Internet. To access the update application, open the diagnosis application and click UPDATE, shown as below: Fig 3-1 Sample of Update When downloading software, the page will display the number... - Page 25 Fig 3-2 Sample of Updating *Xtool Devices support bilingual upgrades, usually English and the local language. To switch other languages, please contact your dealer.
-
Page 26: Diagnosis
(ABS), airbag system (SRS), and perform kinds of actuation tests. VEHICLE CONNECTION The diagnosis operation needs to connect the PS70PRO smart diagnosis system to a vehicle first so that the tablet can establish correct vehicle communication. Please perform the following steps: Turn on the tablet;... -
Page 27: Diagnosis
The connection method is shown in the figure below: Fig 4-1 Sample of How to Connect Vehicle & Device Tablet Main Test Cable OBDII-16 Connector Vehicle *Caution: Please make sure all the cables are connected tightly; The vehicle’s DLC is not always located under the dash; for the location of the DLC, please refer to the vehicle’s user manual. -
Page 28: Vehicle Selection
VEHICLE SELECTION PS70PRO Smart Diagnosis System supports 2 ways to access the vehicle diagnosis system. You can select "Automatic Detection" or "Manual Selection" to enter the diagnosis system. Automatic detection will automatically identify the vehicle's VIN code, and then read the information of your target diagnostic object. -
Page 29: Basic Functions
Enter "manual selection", you can also diagnose the car according to the system according to your needs after selecting the model. Fig 4-3 Sample of Diagnosis Methods BASIC FUNCTIONS The diagnosis system supports 5 basic diagnosis functions, as follows: Read ECU ... - Page 30 Fig 4-4 Sample of Basic Functions Read ECU Information: This function is to read ECU version information, which is the equivalent of "System Identification" or "System information in some electronic control systems, all mean to read ECU related software and hardware versions, models, and production date of diesel engine, part number, etc.
- Page 31 Fig 4-5 Sample of ECU Info Read Trouble Code: Read trouble codes stored in ECU. Fig 4-6 Sample of reading Codes...
- Page 32 *Tip: In the process of diagnosis, if the device shows “System is OK” or “No Trouble Code”, it means there is no related trouble code stored in ECU or some troubles are not under the control of ECU, most of these troubles are mechanical system troubles or executive circuit troubles, it is also possible that signal of the sensor may bias within limits, which can be judged in Live Data.
- Page 33 Suggestion: users should better not clear trouble codes, we need to record the trouble details after reading the code, which is provided as a reference for maintenance. After dealing with troubles, there will be no trouble code when we re-read. Read Live Data: that is to read the parameters of running engine, such as oil pressure, temperature, engine speed, fuel oil temperature, coolant temperature, intake air temperature,...
- Page 34 Fig 4-9 Sample of Multi-line Chart In the process of diagnosis, if the device shows “System is OK” or “No Trouble Code”, it means there is no related trouble code stored in ECU or some troubles are not under the control of ECU, most of these troubles are mechanical system troubles or executive circuit troubles, it is also possible that signal of the sensor may bias within limits, which can be judged in Live Data.
- Page 35 This function allows the device to send information to and receive information from, vehicle control modules. For example, in the case of OBD II generic information Mode 1 (which relates to data parameters), the scan tool user initiates a request for information from the powertrain control module (PCM), and the PCM responds by sending the information back to the scan tool for display.
-
Page 36: Special Functions
The special functions interface is shown as below: Fig 5-1 Sample of Special Functions Note All special functions supported by PS70PRO are subject to the actual special functions displayed on the device. Due to the limitation of screenshots, the special functions shown in... -
Page 37: Oil Reset
5.1 OIL RESET Reset the Engine Oil Life System, which calculates the optimum oil life change interval based on the vehicle’s driving conditions and climate. The oil life reminder must be reset each time the oil is changed so that the system can calculate when the next oil change is required. - Page 38 Figure 5-2 Sample of oil reset function (screen 1) Enter Maintenance mileage reset menu. Input reasonable value of mileage and press OK. Figure 5-3 Sample of oil reset function (screen 2) Message of ‘Reset success’ displayed when Oil Reset function has successfully performed.
-
Page 39: Epb
5.2 EPB Electronic Parking Brake (EPB) System reset is a popular special function. You can use this function to reset the electronic parking brake system and brake pads, which also supports the brake pad replacement (retraction, release of the brake pump), G-sensor, and body angle calibration. This function has multiple uses and can safely and effectively maintain the electronic brake system. - Page 40 Figure 5-4 Sample of EPB function (screen 1) Enter the Enter maintenance mode menu and release the handbrake brake. And press OK after completing the instructions shown. Figure 5-5 Sample of EPB function (screen 2) Wait until the message of ‘Successful operation’ popes up.
-
Page 41: Sas
5.3 SAS Steering Angle Sensors (SAS) System Calibration permanently stores the current steering wheel position as the straight-ahead position in the SAS EEPROM. Therefore, the front wheels and the steering wheel must be set exactly to the straight-ahead position before calibration. In addition, the VIN is also read from the instrument cluster and stored permanently in the SAS EEPROM. - Page 42 Figure 5-6 Sample of SAS function (screen 1) Wait until the following instruction is displayed and press Yes after completing the instructions shown. Figure 5-7 Sample of SAS function (screen 2)
- Page 43 Follow the instructions displayed and press OK after completing the instructions shown. Figure 5-8 Sample of SAS function (screen 3) Wait until the following instruction is displayed and press OK after completing the instructions shown. Figure 5-9 Sample of SAS function (screen 4)
-
Page 44: Dpf
Message of ‘Function execution is completed’ displayed when SAS function has successfully performed. 5.4 DPF The Diesel Particle Filter (DPF) function manages DPF regeneration, DPF component replacement teach-in, and DPF teach-in after replacing the engine control module (ECM). The ECM monitors driving style and selects a suitable time to employ regeneration. - Page 45 The operation guidelines of the DPF function are shown as below: Enter the DPF menu and choose relevant models according to the vehicle being tested. Enter the DPF regeneration menu. Read carefully and complete the requisites listed before performing the DPF regeneration function. And press OK after completing the instructions shown.
- Page 46 Figure 5-11 Sample of DPF function (screen 2) Read the note carefully and follow the instructions shown on the screen. And press OK after completing the instructions shown. Figure 5-12 Sample of DPF function (screen 3)
- Page 47 Follow the instructions displayed and press OK after completing the instructions shown. Please pay attention to the Note. Figure 5-13 Sample of DPF function (screen 4) Press the OK button to start the regeneration. Figure 5-14 Sample of DPF function (screen 5)
- Page 48 10. Wait for the value of carbon deposit to decrease until a message of ‘Emergency regeneration has been completed’ popes up, this process may take up to 40 minutes. Figure 5-15 Sample of DPF function (screen 5) 11. Wait for 2 minutes to let the particulate filter cool down. Figure 5-16 Sample of DPF function (screen 6) 12.
-
Page 49: Bms Reset
5.5 BMS RESET The Battery Management System (BMS) allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle. This function enables you to perform a resetting operation on the monitoring unit of the vehicle battery, in which the original low battery fault information will be cleared and battery matching will be done. - Page 50 Enter the BMS Reset menu and choose relevant models according to the vehicle being tested. Turn on the ignition switch. Press OK to continue the BMS function. Enter battery capacity (within the given range) and press OK after the input. Figure 5-17 Sample of BMS function (screen 1) Enter the battery manufacturer and press OK after the input.
- Page 51 Figure 5-18 Sample of BMS function (screen 2) Enter the 10-digit battery serial number and press OK after the input. Figure 5-19 Sample of BMS function (screen 3)
-
Page 52: Throttle
5.6 THROTTLE Throttle Position Sensor (TPS) Match, this function enables you to make initial settings to throttle actuators and returns the “learned” values stored on ECU to the default state. Doing so can accurately control the actions of regulating throttle (or idle engine) to adjust the amount of air intake. - Page 53 Wait until all the parameters are read and displayed. Figure 5-21 Sample of throttle function (screen 2) Press the F2 button and wait until a message of ‘Match successfully’ pops up.
-
Page 54: Injector Coding
5.7 INJECTOR CODING This function can write the identification code of the fuel injector into the ECU so that the ECU can recognize and work normally. Write actual injector code or rewrite code in the ECU to the injector code of the corresponding cylinder for controlling accurately and correcting cylinder injection quantity. - Page 55 Figure 5-22 Sample of injector coding function (screen 1) Read and confirm the value stored in the cylinders. Figure 5-23 Sample of injector coding function (screen 2)
- Page 56 Enter the Change the value of cylinder menu of the replaced injector(s), enter the new 5-digit value, and then press OK. Figure 5-24 Sample of injector coding function (screen 3) Wait until the message ‘Write successfully’ pops up. Turn off the ignition switch. Wait until the message asked you to turn on the ignition switch.
-
Page 57: Gearbox Match
5.8 GEARBOX MATCH After changing the gearbox or changing the gearbox ECU, you need to use the gearbox matching function to re-match the engine and the gearbox. Before resetting the gearbox, please check the gearbox control unit to ensure that there is no fault code. -
Page 58: Gear Learning
5.9 GEAR LEARNING The crankshaft position sensor learns crankshaft tooth machining tolerance and saves to the tablet to more accurately diagnose engine misfires. If gear learning is not performed for a car equipped with a Delphi engine, the MIL turns on after the engine is started. - Page 59 Figure 5-27 Sample of gear learning function (screen 1) Read the instructions displayed and press Yes to start the learning process. Figure 5-28 Sample of gear learning function (screen 2)
-
Page 60: Settings
Release the accelerator pedal and press OK to exit the gear learning function. ETTINGS Click the Settings button to adjust the default settings and view information about the PS70PRO Smart Diagnosis System. There are seven options available in the system settings: Language ... - Page 61 After the configuration is successfully changed, you can switch the target language. Fig 6-1 Sample of Language Settings This will only change the language of the APP. If you want to change the system language, please go to Android Settings. How to change the language of your software? ...
-
Page 62: Units
Step4: Back to Updates to pull all packages again UNITS You can switch the unit used by the system. PS70PRO Smart Diagnosis System provides you with Metric, Imperial, and U.S. units. You can directly click on the unit you need, after the switch is successful, a blue checkmark will be displayed behind the unit’s name. -
Page 63: My Workshop Info
MY WORKSHOP INFO Click on My Workshop Information, you can input your workshop information here. As shown in the figure below, you just need to fill in the valid information in the corresponding column and click "SUBMIT". And then it will show your workshop information in the report when you generate a diagnostic report, including your company name, address, website, telephone, and mailbox. -
Page 64: Firmware Information
FIRMWARE INFORMATION Fig 6-4 Sample of Firmware Information You can view the firmware information here, including the firmware name, the latest firmware version, the currently used firmware version, and the firmware type. The diagnosis tablet supports automatic firmware update, please make sure that the device is connected to the network when you enter the diagnostic software and the firmware will be automatically updated to the latest version. -
Page 65: About
ABOUT Tap on ABOUT, you can check the serial number and APP version on here. Fig 6-5 Sample of About... -
Page 66: Report
EPORT Diagnostic Report is used for viewing and printing the saved files, such as Live Data, Trouble Codes, or pictures generated in the process of diagnosis, users also can view a record of which cars have been previously tested. It includes 3 parts: Report ... - Page 67 Fig 7-2 Sample of Report Records When you open the report, located in the header of the table is the studio information you filled in advance in the system setup, then the information of the vehicle, as shown as below: Fig 7-3 Sample of Report Print PDF Report ...
-
Page 68: Replay
IP address of the printer in the APP, or you can contact your dealer for help. PS70PRO Smart Diagnosis System doesn’t provide the printer driver software, please install a third part App on the tablet if you need the print your diagnosis report. -
Page 69: File Manager
Before replaying the living data, please make sure you have recorded the live data during the diagnosis Fig 7-6 Sample of Live Data Replay FILE MANAGER This function allows you to check and delete files on the device. Please use this function under the guidance of professionals. Ordinary users are not recommended to use it by themselves, as it may cause software missing or malfunctioning. -
Page 70: Remote Assistance
To obtain remote support from your partners or XTOOL After- service Center: 1. Turn on the power of the tablet. - Page 71 Fig 8-1 Sample of Team Viewer Starting 2. Click Remote in the diagnosis application. The TeamViewer screen is displayed, and the device ID will be generated. Fig 8-2 Sample of Team Viewer ID...
- Page 72 4. Provide your ID to the partner or XTOOL technician, and then wait for him/her to send you a remote-control request.
-
Page 73: Factory Reset
ACTORY ESET Once the device is restored to factory settings, historical data cannot be restored. Please use this function under the guidance professional technicians. Xtooltech responsible for all economic losses caused by restoring factory settings, please use this function with caution. Here are the steps to restore factory settings Step 1 Clicking Settings Fig 9-1 Sample of FACTORY RESET (Screen 1) - Page 74 Step 2 Click on Factory Data Reset Fig 9-2 Sample of FACTORY RESET (Screen 2) Step 3 Click on Reset Device Fig 9-3 Sample of FACTORY RESET (Screen 3)
- Page 75 Step 4 Click on ERASE EVERYTHING Fig 9-4 Sample of FACTORY RESET (Screen 4) After you complete the above operations, the device will automatically restart and enter the factory mode to pull the new software. Please keep the network stable and follow the instructions on the page.
- Page 76 Fig 9-5 Sample of Select Language After selecting the system language, click Next to enter the Wi- Fi connection page, as shown below: Fig 9-6 Sample of Wi-Fi Connection Select a network to connect to on the Wi-Fi connection page.
- Page 77 After successful network connection, the automatic system will jump to Factory mode to download the software: Fig 9-7 Sample of Factory Mode Once the software has been downloaded, the tablet will automatically reboot and request the system language selection again.
- Page 78 Fig 9-8 Sample of Language Selection Since restoring the factory settings will erase the user information on your device, you need to enter the email again to Note Once the device is reset to factory settings, historical data cannot be recovered. Please use this feature with caution. In addition, if you restore factory settings after the expiration date, Xtooltech is not responsible for restoring historical data for you.
-
Page 79: Faq
10 FAQ Q1: FAILED TO GENERATE DIAGNOSIS REPORT 1. Currently only perform diagnostic functions, that is, read ECU information, read code and clear code, live data, freeze frame, which can trigger a diagnostic report. Other functions, such immobilization maintenance services will not be displayed in the report. 2. - Page 80 Fig 10-1 Sample of How to Clear APP Cache (Screen 1) Fig 10-2 Sample of How to Clear APP Cache (Screen 2)
-
Page 81: Q2: How To Print Diagnosis Report
OS settings. After the setting is completed, you can print it in the Report. Q3: FAILED TO EXTRACT FILES Since the XTOOL tablet is equipped with an Android system, you have to confirm the system type of receiver. For Android: supports transferring files via Bluetooth, USB cable, etc.;... -
Page 82: Q4: Mailbox Supported
Q6: HOW TO GENERATE AND UPLOAD DIAGNOSTIC LOG FILES The PS70PRO tablet will automatically generate and store the diagnostic logs. When the device is connected to the Internet, it will automatically upload all the stored diagnostic logs to the backend system. -
Page 83: Q8: Failed To Diagnose Vehicle
Q8: FAILED TO DIAGNOSE VEHICLE 1. Contact your dealer to confirm whether the vehicle model is supported by the scan tool you owned. 2. Check whether the vehicle is properly connected (e.g. whether the ignition is ON, and the diagnosis of some vehicles need to turn on the engine), If your tablet is equipped with a VCI box, please check the status of the VCI box indicator. -
Page 84: Q11: Failed To Open The Diagnosis App
and hold the power button for 4-5 seconds until the boot animation is shown on screen. Q11: FAILED TO OPEN THE DIAGNOSIS APP The tablet has to connect to the network every 30 days, otherwise, the diagnosis app will be locked and disabled until the device is connected to the network. - Page 85 Shenzhen Xtooltech Intelligent Co., Ltd Company address: 17&18/F, Building A2, Creativity City, Liuxian Avenue, Nanshan District, Shenzhen, China Factory address: 2/F, Building 12, Tangtou Third Industrial Zone, Shiyan Street, Baoan District, Shenzhen, China Service-Hotline: 0086-755-21670995/86267858 Email: marketing@xtooltech.com Fax: 0755-83461644 Website: www.xtooltech.com...
