- Page 1 Gloss Single Unit White Spare Parts Customer Support www.argos-support.co.uk 0345 640 2020 Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 13/08/19...
- Page 2 Safety and Care Advice Product Details 465/9732 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. • Keep children and animals away • Assemble the item as close to • We do not from the work area, small parts recommend the could choke if swallowed.
- Page 3 Fittings Bag 1 35mm Male Camlock x 10 12mm Female Camlock x 6 40mm Screw x 4 25mm Screw x 4 Dowel x 10 25mm Machine Screw x 8 Hexagon Key x 1 14mm Screw x 12 12mm Screw x 8 Wall Strap x 1 Washer x 2 14mm Screw x 1...
-
Page 4: Tools Required
Tools required Phillips screwdriver Ruler/tape (small & medium) measure Mallet Eye protection (when using a hammer or glue) - Page 5 Panels Top Panel x 1 Right Side Panel x 1 Left Side Panel x 1 34(w) x 28.5(d) x 1.5(h)cm 71(w) x 28.5(d) x 1.5(h)cm 71(w) x 28.5(d) x 1.5(h)cm Back Panel x 1 Shelf x 1 Back Panel x 1 30.9(w) x 6(d) x 1.5(h)cm 30.8(w) x 26.8(d) x 1.2(h)cm 71.9(w) x 31.8(d) x 0.3(h)cm...
- Page 6 Drawer Front Panel x 1 Drawer Right Panel x 1 Metal Foot x 2 34(w) x 22(d) x 1.5(h)cm 25(w) x 14(d) x 1.2(h)cm Drawer Left Panel x 1 Drawer Back Panel x 1 Drawer Bottom Panel x 1 25(w) x 14(d) x 1.2(h)cm 26.1(w) x 14(d) x 1.2(h)cm 27(w) x 24.6(d) x 0.3(h)cm...
- Page 7 35mm Male Camlock x 10 12mm Female Camlock x 6 40mm Screw x 4 25mm Machine Screw x 8 35mm Male Camlock x 6 25mm Screw x 4 Dowel x 10 25mm Machine Screw x 8 Hexagon Key x 1 14mm Screw x 12 12mm Screw x 8 12mm Screw x 4...
- Page 8 14mm Screw x 4 Hinge x 2 Female Camlock x 2 Dowel x 2...
- Page 9 Female Camlock x 4 Dowel x 4...
- Page 10 40mm Screw x 4 Dowel x 4 Wall Strap x 1 Washer x 1 Buckle x 6 14mm Screw x 6 25mm Screw x 4 14mm Screw x 1...
- Page 11 Shelf Support x 4...
- Page 12 14mm Screw x 8...
- Page 13 35mm Male Camlock x 4 12mm Screw x 4 10mm Female Camlock x 4 Runner x 1 Runner x 1 30mm Screw x 4 Step 1 Step 2 Step 3 Step 4 Step 5...
- Page 14 Wall fixings are not supplied Washer x 1 WARNING!
-
Page 15: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important note: Important: when drilling into walls always check that there are no hidden wires or pipes etc. If plastic wall plugs (rawl plugs) Make sure that the screws and wall plugs being used are suitable for are supplied with your product, Hints: 1.
