09H Sophia Motif 5FT FO
Assembly Instructions -
Dimensions
Width - 211.1cm
Depth - 159.7cm
Height - 110cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800.
For further assistance please visit http://www.argos-support.co.uk/.
Please keep for future reference
464/4084
Issue 1 - 13/05/16
Advertisement
Related Manuals for Argos 464/4084
Summary of Contents for Argos 464/4084
- Page 1 Depth - 159.7cm Height - 110cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/. Issue 1 - 13/05/16...
- Page 2 Depth - 159.7cm Height - 110cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/. Issue 1 - 17/12/15...
- Page 3 Safety and Care Advice Important - Please read these instructions fully before starting assembly · Do not stand or put weight on · Check you have all the · To reduce components and tools listed on the product, this could cause the likelihood of pages 2 and 3.
- Page 4 If you have damaged or missing componets, call the Components - Panels Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/ Please check you have all the panels listed below Headboard × 1 (159.7× 110cm) Footboard × 1 (159.7 ×36.5cm) Bed Frame ×...
- Page 5 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Ø8 ×95mm Connector × 4 Bolt ×...
- Page 6 Assembly Instructions Step 1 a. Fixing bolts Insert 4 bolts into Headboard Footboard b. Fixing Angle Fixing Angle onto the Footboard Headboard by 4 Screw c. Cover Cap Cover the Cap to the holes in the Footboard. Note: There are 2 panels inside the frame of the headboard and footboard, if there is a gap within...
- Page 7 Assembly Instructions Step 3 Fixing the Bed Frame Two people are needed here. Fix the side frame onto the Headboard Insert 4 Connectors into Side Frame shown. Use Allen wrench turn Nut lockwise to lock. Cover the cap to the holes in the side frame.
- Page 8 Assembly Instructions Step 5 a. Fixing the Center Rail Fixing the Center Rail onto the unit by 4 Screws and Allen Key b. Fixing the Center Support Leg Fixing the Center Support Legs under the Center rail by 4 screws and Allen Key show on picture.
- Page 9 Assembly is complete. If you need help or have damaged or missing parts,call the Customer Helpline: 03456 400800 Retailer: Argos Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9,2NW For further assistance please visit http://www.argos-support.co.uk/...
