Canterbury 5 DRW CHEST
Assembly Instructions
Dimensions
Width - 55.8cm
Depth - 41.9cm
Height - 106.1cm
Important
– Please read these instructions carefully before starting the assembly
71935
C
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please save for future reference
497/0916
460/6668
501/8516
19
kg
42
lbs
6
kg
12
lbs
max.
www.tvilum.com
71935 Version F Date 04/09/2017
Advertisement
Related Manuals for Argos Canterbury 5 DRW CHEST
Summary of Contents for Argos Canterbury 5 DRW CHEST
- Page 1 Canterbury 5 DRW CHEST Assembly Instructions 497/0916 - Please save for future reference 460/6668 501/8516 max. Dimensions Width - 55.8cm Depth - 41.9cm Height - 106.1cm Important – Please read these instructions carefully before starting the assembly 71935 www.tvilum.com If you need help or have damaged or missing parts, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important – Please read these instructions carefully before starting the assembly • Check that you have all the • During assembly, do not stand • We do not components and tools listed on or put weight on the product, recommend the use the following pages.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check that you have all the panels as listed below FC Side panel x2 (102.8 x 39 cm) FC Side panel x2 (102.8 x 39 cm) IB Bottom panel (55.8 x 41.9 cm)
- Page 4 Components - Fittings Please check that you have all the fittings as listed below Note: The quantities listed in the following are the correct amounts to complete the assembly. In some cases, more fittings may be supplied than required. 10401 17414 20203 Panel clips x8...
- Page 5 Assembly Instructions Step 1 Fittings you will need for this step: Insert cam bolts Cam bolt #31513 x8 Insert cam bolts 31513 into the top and bottom panel LD and IB . Cam bolt must be screwed down flush with the surface.
- Page 6 Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 3 Fittings you will need for this step: Place drawer runners Flat head screw Flat head screw Drawer runner #25233 x20 #26020 x20 #41404 x10 Extend drawer runner 41404 and make sure to note which way it runs. Place drawer runner 41404 so that they face the fronts of side panels...
- Page 7 Assembly Instructions Step 4 Attach bottom panel Press the bottom panel IB into the side panels FC . Make sure that the finished edge is facing towards the front and that the unfinished side is facing towards the bottom of the case. Tighten the cams with a screwdriver, as illustrat- 9,8 cm...
- Page 8 # $PRPVIEW:{Pos_Beslag} Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 5 Attach back panel Slide back panel 09784 smoothly down into the grooves of the side panels FC and the bottom panel IB . 09784 09784 9,8 cm 9,8 cm Step 6 Attach top panel Attach the top panel LD by inserting dowel pins and cam bolts into the...
- Page 9 Assembly Instructions # $PRPVIEW:{Pos_Be Step 7 Fittings you will need for this step: Wedges Assemble profiles # $PRPVIEW:{Pos_Beslag} #33204 x4 Insert wedges 33204 76425 into slots on the angle ends of side and front profiles 76426 + 76317 + 76425 . 76425 Please use a hammer for 76426...
- Page 10 Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 9 Fittings you will need for this step: Assemble profiles Dowel Glue # $PRPVIEW:{Pos_Beslag} Insert dowels 20203 #20203 x6 #22601 x1 into outer holes on the assembled profiles. Use glue 22601 as 76425 illustrated. 76426 76425 Add one small drop of 76317...
- Page 11 # $PRPVIEW:{Pos_Beslag} Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 11 Fittings you will need for this step: Attach base rail Tape dots #17414 x1 Flip the cabinet so that it stands on its bottom 31-0 panel. Attach the tape dots 17414 on the base rail Bille 76318 76318 .
- Page 12 Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 13 Fittings you will need for this step: Attach back panels Panel clips Floor Gliders #10401 x8 #63008 x4 Important: The unit MUST be square when the panel clips are attached. Lay the cabinet face down on the floor.
- Page 13 Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 14 Fittings you will need for this step: Fix the unit to a wall Strap #94009 x1 Fix the unit to a wall with strap 94009 . 94009 The screw supplied together with the anti-topple bracket is to be used only for fixing the anti-topple bracket...
- Page 14 Assembly Instructions Step 15 # $PRPVIEW:{Pos_Beslag} Fittings you will need for this step: Assemble drawers Dowel Cam bolt #20203 x20 #31513 x10 #31687 x10 Attach cam 31687 into # $PRPVIEW:{Pos_Beslag} the holes in left and right drawer side 00751 + 00752 .
- Page 15 Assembly Instructions # $PRPVIEW:{Pos_Beslag} Step 17 # $PRPVIEW:{Pos_Beslag} Attach drawer bottom Press the drawer bottom 06081 smoothly into the grooves with the finished side turning up. Step 18 Attach drawer front Attach the drawer front EA by placing the dow- els and cam bolts in the 06081 correct holes.
- Page 16 Assembly Instructions # $PRPVIEW:{Pos_Beslag} # $PRPVIEW:{Pos_Beslag} Step 19 Fittings you will need for this step: Attach the handle Machine screw Handle #26232 x5 #81040 x5 Attach the handle 81040 to the drawer front EA Use machine screw 26232 to tighten the Bille handle.
- Page 17 26214 from the inside of the drawer in both sides. Repeat this procedure for each of the remaining drawers. Assembly is completed. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
