Avalon 4'6 and 5' Bed
Assembly Instructions
Dimensions (4'6)
Length - 200cm
Width - 149cm
Height - 104cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
– Please keep for future reference
Dimensions (5')
Length - 210cm
Width - 164cm
Height - 104cm
634/2724
634/2755
634/2786
634/2731
634/2762
634/2793
Issue 1 - 24/10/12
Advertisement
Related Manuals for Argos Avalon 4'6
Summary of Contents for Argos Avalon 4'6
- Page 1 Avalon 4'6 and 5' Bed Assembly Instructions 634/2724 – Please keep for future reference 634/2755 634/2786 634/2731 634/2762 634/2793 Dimensions (4'6) Dimensions (5') Length - 200cm Length - 210cm Width - 149cm Width - 164cm Height - 104cm Height - 104cm Important –...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Make sure you have enough • Assemble on a soft level components and tools listed on space to layout the parts before surface to avoid damaging the pages 2 and 3. -
Page 3: Components - Parts
Components - Parts Please check you have all the parts listed below Headboard corner post (right) ( 101 x Ø3.2cm) Headboard corner post (left) ( 101 x Ø3.2cm) Horizontal rail (4’6- 143×Ø1.9cm) (5'- 157 x Ø1.9cm) Footboard corner post (right) ( 40 x Ø3.2cm) Footboard corner post (left) ( 40 x Ø3.2cm) -
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Assembling corner posts Lay headboard posts HEADBOARD flat onto the floor with the holes facing up. Holes to face up Assemble horizontal rails in between corner posts using screws Note: Horizontal rails fit inside the large holes in posts Repeat using footboard corner posts...
- Page 6 Assembly Instructions Step 3 Assembling side rails Assemble side rails together using screws Repeat for the other side rail. Step 4 Assembling slats Assemble slats one side rail only, using screws Note: Slats have a thread in each end.
- Page 7 Assembly Instructions Step 5 Assembling slats Locate slats into the remaining holes in the side rail. Note: Slats have no threads in the end and do not require fixing. Step 6 Assembling bed base With help, locate the remaining side rail onto the ends of the slats.
- Page 8 Assembly Instructions Step 7 Assembling Assembling main frame With help, assemble side rails to the headboard using fixings Assemble the footboard to the side rails using fixings Assemble support leg to the underside of the side rail using screws Repeat on both sides.
- Page 9 Assembly Instructions Step 8 Assembling slat supports Assemble central supports and support legs through slats using screws Note: Central supports fit underneath the slats. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Home Retail Group.
