Calgary - Corner Desk

Assembly Instructions -

Dimensions

Width - 100cm

Depth - 82cm

Height - 74cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, please visit www.argos-support.co.uk

or email: Help@ClickSpares.co.uk (quoting your original order number)

Alternatively, call the Spares Helpline on: 0370 112 1928.

For any other queries please contact the Customer Helpline on: 0345 640 2020

Please keep for future reference

Shelf section on the left

Shelf section on the right

476/7978

462/6930

MADE IN

BRITAIN

Issue 1 - 25/11/15

Need help?

Do you have a question about the Calgary 476/7978 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Calgary 476/7978

Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 24kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
Page 5 Assembly Instructions Step 1 DO NOT USE the shelf base. Prepare the shelf It is similar to the shelf panel panel but, it has a shallow mark hole. Insert 4 large locking nuts into the shelf panel Note: The arrows on the locking nuts must point towards the holes in the edge of the panels.
Page 6 Assembly Instructions Step 3 Fit a divider to the shelf panel Tap 2 double metal dowels through the holes in the middle of the shelf panel and push a divider onto them until they ‘’bottom out’’. Use a screwdriver to tighten the 2 large locking nuts fitted to...
Page 7 Assembly Instructions Step 5 Prepare the shelf base Insert 4 large locking nuts into the shelf base Tap 4 wooden dowels Turn the into the shelf base shelf base over Turn the shelf base over Screw 2 metal dowels into the shelf base Note: Tighten the metal dowels up fully against...
Page 8 Assembly Instructions Step 7 Prepare the 2 shelf ends Screw 4 metal dowels into each of the 2 shelf ends Insert 2 large locking nuts into each of the 2 shelf ends Step 8 Fit a shelf end Push a shelf end onto the assembly.
Page 9 Assembly Instructions Step 10 Prepare the shelf top Screw 6 metal dowels into the shelf top Step 11 Fit the shelf top Push the shelf top onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the 2 shelf ends the divider Step 12...
Page 10 Assembly Instructions Step 13 Prepare the end panel Screw 2 metal dowels into the end panel Insert 2 large locking nuts into the end panel Step 14 Prepare the back panel Insert 4 large locking nuts into the back panel Step 15 Fit the back panel to the end panel...
Page 11 Assembly Instructions Step 16 IMPORTANT ! Only follow the 2 steps on this Prepare the desktop page if you are going to have Screw 4 metal dowels the shelf section on the left. into the desktop If you are going to have the shelf section on the right, follow Tap the 4 plastic inserts the 2 steps on the next page.
Page 12 Assembly Instructions Step 18 IMPORTANT ! Only follow the 2 steps on this Prepare the desktop page if you are going to have Screw 4 metal dowels the shelf section on the right. into the desktop If you are going to have the shelf section on the left, follow the 2 Tap the 4 plastic inserts steps on the previous page.
Page 13 Assembly Instructions Step 20 IMPORTANT ! Only follow this step if you are going to Fit the desktop to the have the shelf section on the left. shelf top If you are going to have the shelf section Lower the desktop on the right, follow the next step.
Page 14 Assembly Instructions Step 21 IMPORTANT ! Only follow this step if you are going to Fit the desktop to the have the shelf section on the right. shelf top If you are going to have the shelf section Lower the desktop on the left, follow the previous step.
Page 15 Assembly Instructions Step 22 Assembly is complete If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
Page 16 ALR3275...
