Flight Model F0081 Katana 26-30CC Assemble Manual
  1. Manuals
  2. Brands
  3. Flight Model Manuals
  4. Toy
  5. F0081 Katana 26-30CC
  6. Assemble manual

Flight Model F0081 Katana 26-30CC Assemble Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Wing Span:70in/1780mm;
Wing Area:61sq.dm;
Length:62.9in/1600mm
CAUTION : this plane is not a toy!
Before use , please carefully read this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:3600g;
Radio:6channels 5servos;
Engine:26-30CC GAS;
P1

Advertisement

loading
Need help?

Need help?

Do you have a question about the F0081 Katana 26-30CC and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Model F0081 Katana 26-30CC

Summary of Contents for Flight Model F0081 Katana 26-30CC

  • Page 1 Wing Span:70in/1780mm; Flying Weight:3600g; Wing Area:61sq.dm; Radio:6channels 5servos; Length:62.9in/1600mm Engine:26-30CC GAS; CAUTION : this plane is not a toy! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .

  • Page 2: Kit Contents

    KIT CONTENTS...

  • Page 3: Main Wings

    MAIN WINGS AB GLUE Connect the aileron and main wing with horns. The finished picture as shown. Pay attention to glue firmly. Cut away covering film for the servo.
  • Page 4 Install the tri-horn and servo arm with pushrod as shown. Measure the length of the extention . Pull out the extention from the rib of the main wing.
  • Page 5 Find out the holes in each sides of fuselage, then cut the film. Connect the main wings and the fuselage with joiner. Also pull the extension into the fuselage. Fixup the wings with nylon screws as shown.

  • Page 6: Main Landing Gear

    MAIN LANDING GEAR Install the wheel with screw and collars as shown. Fixup the wheel to the landing gear by screw. Use two TP screws to fix the wheel cover to the landing gear.

  • Page 7: Tail Wheel

    Install the main landing gear on the bottom of the fuselage. Pay attention to:we have CB and AL landing gear for choice. and the assembly way is the same. TAIL WHEEL Find and cut the hole for stabilizer and also the servo holes.
  • Page 8 Cut the rudder film along the edges, and glue the rudder to the fuselage. Securely glue up and soaked up the hinge with instant glue. Bend the tail landing gear to fit for the rudder and insert it into the rudder.
  • Page 9 Glue the rudder to the fuselage. Glow the tail landing gear to the rudder securely. Install the tail wheel, and fasten the presser of the tail wheel to the stabilizer by screws.
  • Page 10 ELEVATOR AND RUDDER Insert elevator to the tailplane with U shape wire. Connect the control horn to the linkage of the servo. Tighten the second loop through the brass swage tube.
  • Page 11 Crimp the brass tube with a crimping tool or pliers. Push rods Rudder servo arm Install rudder pushrod.
  • Page 12 ENGINE Gather the MLD engine and spare parts as shown. The finished picture as shown. Pay attention to:you have DLE and MLD for choice. Install the DLE 30CC as shown.
  • Page 14 Place the hatch. Use two screws to secure it firmly. COWLING Mounting the cowling by wood screws. FUEL TANK...
  • Page 15 CG POSITION & CONTROL THROWS MEASUREMENT...
  • Page 16 FINISHED PICTURE Flight Model MFG CO . ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town,Dong Guan City,Guang Dong Province,China Tel: +86-769-85070618 / +86-769-81627996 / +86-769-89790965 Fax: +86-769-85091868 E-mail:info@flight-model.com / flight_model@126.com Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/...
