Flight Model ME-110 Assemble Manual
  1. Manuals
  2. Brands
  3. Flight Model Manuals
  4. Toy
  5. ME-110
  6. Assemble manual

Flight Model ME-110 Assemble Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Caution:this plane is not a toy!
Before use ,please carefully read this
manual.
Wing Span:59.1in/1800mm;Flying Weight:3000g;
Wing Area:47sq.dm;
Length:43.6in/1330mm;
Radio:6-7channels 11-12servos;
Engine:2C 46 twin engine powered;

Advertisement

loading
Need help?

Need help?

Do you have a question about the ME-110 and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Model ME-110

Summary of Contents for Flight Model ME-110

  • Page 1 Caution:this plane is not a toy! Before use ,please carefully read this manual. Wing Span:59.1in/1800mm;Flying Weight:3000g; Wing Area:47sq.dm; Radio:6-7channels 11-12servos; Length:43.6in/1330mm; Engine:2C 46 twin engine powered;...
  • Page 2 Install The Retract Wheels On Main Wing Gather the carbon joiner,main wings and other parts. Apply AB glue to all sides of each hinges, to connect the aileron. Find out and cut the holes for the servos .
  • Page 3 Assemble Mechanical Retracts Istall front wheel as show. Use four 3*12 screws to fixup mechanical retracts. Assemble Mechanical Retract servo as show.
  • Page 4 Istall throttle servo as show. The finished picture as show. The other side as show.
  • Page 5 Apply AB glue to fixup servo to the plywood. Screw the servo to the wood. Assemble flap servo as show.
  • Page 6 Assemble aileron servo as show. Assemble The Air Operated Retracts Assemble the air tube as show. Use 3*12 screws to fixup air operated retracts.

  • Page 7: Glow Engine Installation

    Glow engine installation Assemble the engine. Assemble throttle pushrod as show. Join the wing Apply AB glue to gether right&left wings.
  • Page 8 Put out the extentions and air tubes from the main wing. Fixup the main wing to the fuselage with two screws. Apply AA glue to fixup the decoration plastic to the fuselage.

  • Page 9: Install The Tail Wheel

    Install The Tail Wheel Loop the cable back through the brass swage tube as show. Crimp the brass tube with a criming tool or pliers. Assemble tail wheel swing construction.

  • Page 10: Install Elevator Servo

    Tail wheel collar as show. Screw four TP screws to fix up the tail wheel on the tail of the fuselage. Install Elevator Servo Find out and cut the holes for the servos and servo extention...
  • Page 11 Apply AB glue to fixup servo to the plywood. Screw the servo to the wood. Insert the 9g servo into the prepared hole on the elevator.
  • Page 12 Connect the servo wire to the extension then pull out it . Put the standard servo to the elevator servo hole. Link the elevator servo and tri-horns with pushrod. tail wheel servo elevator servo...
  • Page 13 Sanding the position for elevator assemble . Apply instant AB glue to the edge of fuselage and stabilizer. Insert the vertical to the stabilizer. Apply instant type glue to both edge of stabilizer and vertical.
  • Page 14 Another Method To Install Elevator Servo Dill pushrod hole on the fuselage. The elevator rod installation as shown. Assemble elevator servo as show.
  • Page 15 Use the same method to link the rudder servo to rudder. tail wheel servo Air operated retract air tube assemble as show. swich servo Assemble The Canopy Fixup the canopy with TP screw on each side of the canopy.
  • Page 16 Assemble The Cowling Install the cowling with four TP screws. CG & Control Surface Movement...
  • Page 17 The Finished Picture...
