Full-featured TV Bracket
For 17"-42"
62-480mm
Model:1742LM
Installation tools
Stud Finder
Screwdriver
Pencil
Impact Drill
10MM Drill Bit
Wrench
Installation step 1
Confirm the
distance of the
VESA
hole on the back of your TV.
Please confirm that your TV
weight do not exceed 25kg
55lbs
(25kg)
Warning:Please do not
exceed the maximum
load-bearing capacity, which
may cause equipment failure.
Parts List
Punched cardboard (x1)
Bracket (x1)
Cable tie*3
①
What material is your wall made of?
Is it a wood wall?
Self-tapping screw (x4)
A
②
M8*25 (x4)
big spacer (x4)
F
G
③
Installation Step 2
Please confirm your TV hole pitch is
100x100mm or 200x200mm
Please read the instructions thoroughly and have a good understanding of the entire
installation process. Reading the instructions for your TV to see whether there have
any special instructions for using the brackets or not.
WARNING: Avoid potential personal injury and property damage.
1. Please check your wall fastness, suitable for general wood and brick, not
plasterboard wall
2. The wall must be able to carry 5 times the weight (total of the TV plus the bracket)
3. Our company does not bear the loss and damage caused by improper use.
Plastic ancher (x4)
M4*20 (x4)
M5*25 (x4)
B
C
small spacer (x4)
D5 gasket (x4)
D6 gasket (x4)
H
I
.
M6*25 (x4)
D
E
Bubble (x1)
K
J
