TesiraFORTÉ X 400/800/1600
Installation & Operation Guide
Product Description
The TesiraFORTÉ X 400/800/1600 products are conference room DSPs
featuring multiple network and analog audio connection points. With four, eight
and 16 channels of Acoustic Echo Cancellation (AEC) respectively, users can
choose the model that meets the number of microphones required for the room.
FORTÉ X is designed to be used primarily with Biamp's beam-forming
microphones, PoE amplifiers and speakers. A system including these elements
and a UC-room system, display and camera will provide a complete technology
solution for a UC-enabled conference room.
The function of the FORTÉ X is to process local Biamp microphone input and
speaker output signals in support of audio-only and audio/video conference
calls from dedicated conference rooms. The information provided by this manual
relates to physical connections and device setup.
Setup and Use
FORTÉ X works out-of-the-box and requires no configuration nor is Tesira
software required. An embedded, intuitive web interface is provided for setup
and programming. FORTÉ X also offers a programmable platform that requires
an experienced professional to configure.
A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA
Biamp Launch
Biamp Launch technology offers automatic device discovery and tuning without
the need for custom programming. In addition, FORTÉ X provides the user with
a full performance report for the meeting space upon completion.
The Launch may be initiated from the Launch button on the Audio page of the
embedded user interface or from the Launch button on the front of the device
itself. See here for more information on launching the FORTÉ X.
Devices
The FORTÉ X will discover connected devices, configure itself accordingly and
supports the following:
• TCM-1, TCM-1A, TCM-1EX
• TCM-X, TCM-XA, TCM-XEX
• TTM-X, TTM-XEX
• EX-UBT
• AMP-450P, AMP-450BP
• HD-1
