MODENA
Node X 100 & Hub X 100
Installation & Operation Guide
PRODUCT DESCRIPTION
Modena Node X 100 and Modena Hub X 100 are presentation hubs. They
allow participants to connect to meeting room AV equipment and USB
accessories wirelessly, and enable any participant to wirelessly receive AV
streams during a video conferencing session.
These devices also connect to AV peripherals via USB and HDMI, and can
support multiple USB devices via a standard USB hub or by connecting a
Devio SCR-20 or SCR-25.
The information provided by this manual relates to physical connections and
device setup.
A:
9300 S.W. Gemini Drive Beaverton, OR 97008 USA
SETUP AND USE
User devices must be running on Windows, Mac OS X, iOS or Android
operating systems with the Node and Hub's custom drivers and user software
installed.
• Coordinate with local IT administrators before adding Hub or any other
device to a corporate network.
• Should not be placed near potential WiFi obstacles (walls, metallic
surfaces, other radio equipment or signals etc.).
• Keep the Hub away from other devices with a strong electromagnetic
reference such as cordless phones and microwaves.
• Do not exceed the maximum ambient operating temperature of 32-104° F
(0-40° C). Be aware of conditions in an enclosed rack that may cause the
temperature to exceed ambient room conditions.
W:
www.biamp.com
JUN 2022
