4. Click the Programmer icon.
5. Click Detect Cable. The Programmer will detect the cable (Cable: USB2, Port: FTUSB-0).
6. Click the Program icon. When complete, PASS is displayed in the Status column.
MachXO2-1200ZE Breakout Board
This section describes the features of the MachXO2-1200ZE Breakout Board in detail.
Overview
The Breakout Board is a complete development platform for the MachXO2-1200ZE PLD. The board includes a pro-
totyping area, a USB program/power port, an LED array, and header landings with electrical connections to most of
the PLD's programmable I/O, power, and JTAG pins. The board is powered by the PC's USB port or optionally with
external power. You may create or modify the program files and reprogram the board using Lattice Diamond soft-
ware.
Figure 3. MachXO2-1200ZE Breakout Board Block Diagram
Bank 3
2x20 Header
Landing (J4)
Bank 0
2x20 Header
Landing (J2)
GPIO
Programming
GPIO
LCMXO2-1200ZE-
1TG144C
GPIO
2x20 Header
Landing (J5)
Bank 2
MachXO2-1200ZE Breakout Board
Evaluation Kit User's Guide
USB Mini B
USB
Socket
Controller
1x8 Header
Landing (J1,
JTAG
Optional JTAG
Interface)
GPIO
8
6
A/Mini-B
USB Cable
Bank 1
2x20 Header
Landing (J3)
LED
Array
