U NI VE R SAL
C A R G O B ASK E T
IN S TAL L I NSTRU C TIO NS
Please read the mounting instructions below carefully before attempting to install.
Check out the install video on the product page for factory rack disassembly.
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great off-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don't hesitate to call us at 269-459-8447!
Advertisement
Table of Contents
Related Manuals for Victory 4x4 UNIVERSAL CARGO BASKET
Summary of Contents for Victory 4x4 UNIVERSAL CARGO BASKET
- Page 1 Check out the install video on the product page for factory rack disassembly. Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great off-road products. Be sure to rate and review our product online. If you have any questions or are missing parts, please...
- Page 2 I NCLU D E D HARDWARE 1/4"-20 X 3/4" 1/4"-20 X 3/8" Button Head Button Head 1/4” ID 1/4"-20 Washer T-Nut 5/16”-18 5/16”-18 X 3/4” Serr. Flange Nut Button Head...
- Page 3 I NCLU D E D PARTS...
- Page 4 A SS E M BLY Start by attaching a side panel to the thinner side of two of the cross bars. Slide 4 of the 1/4”-20 T-nuts into the channel on the side of the bar, then line them up with the slots in the side panel and bolt them together using the 1/4”-20 X 3/8”...
- Page 5 A SS E M BLY Next, attach a 3rd side panel to the ends of both cross bars. Line the slots on either end of it up with the 2 holes on each of the cross bars and bolt them together using the 1/4”-20 X 3/4” bolts and 1/4” washers. Leave the bolts loose for now.
- Page 6 AS SE M BLY With all the bars loosely installed, bolt the final side panel on to all of them in the same way the third side panel went on. Before bolting it on, slide 6 T-nuts into the channel that is closer to the middle of the basket on each bar.
- Page 7 ASSE M BLY Next, attach the floor panels to the tops of the cross bars. To do this, place a panel onto the bars so that it is perpendicular to the direction of them. Then, slide the T-nuts into position so that they are beneath the holes in the panel.
- Page 8 AS SE M BLY Finally, bolt the small corner brackets into each corner using the 5/16-18 X 3/4” bolts and 5/16”-18 serr. flange nuts.
