MPC837xE-RDS
Reference Design Platform User's Guide
Document Number: MPC837xERDSUG
Rev. 1.0
12/2008
Preliminary, Subject to Change without Notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the freescale MPC837xE-RDS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NXP Semiconductors freescale MPC837xE-RDS

Summary of Contents for NXP Semiconductors freescale MPC837xE-RDS

  • Page 1 MPC837xE-RDS Reference Design Platform User’s Guide Document Number: MPC837xERDSUG Rev. 1.0 12/2008 Preliminary, Subject to Change without Notice...
  • Page 2 How to Reach Us: Information in this document is provided solely to enable system and software implementers to use Freescale Semiconductor products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits or integrated circuits based on the information in this document. Home Page: www.freescale.com Freescale Semiconductor reserves the right to make changes without further notice to any products herein.

  • Page 3: Table Of Contents

    Contents About This Book Audience ..............5 Organization .
  • Page 4 2.5.3 Reset Configuration Word ..........26 2.5.4 Power Supply .

  • Page 5: About This Book

    About This Book This document presents system architecture, board-level functions, external connections, and software features for the MPC837xE-RDS board. It provides guidance of how to operate this product, making it easy for the user to connect with the outside world. The front part of this book focuses primarily on the board and functions.

  • Page 6: References

    Inter-Integrated Circuit (computer bus) EEPROM Electrically Erasable Programmable Read-Only Memory JTAG Joint Test Action Group DHCP Dynamic Host Configuration Protocol Domain Name System VLAN Virtual Local Area Networks Network Address Translation Port Address Translation Routing Information Protocol VRRP Virtual Router Redundancy Protocol PPPoE Point-to-Point Protocol over Ethernet IGMP...

  • Page 7: Introduction

    Introduction Introduction This section presents the features and block diagram for the MPC837xE-RDS board. Overview The MPC837xE-RDS is a reference design based on the MPC8377E PowerQUICC II Pro processor. It supports applications of Wi-Fi Router, DMS (Digital Media Server), NAS with RAID, or Office in BOX, etc.
  • Page 8 Introduction – Two standard External SATA connectors — PCI: 32-bit PCI interface up to 66 Mhz – 2x 32-bit 3.3 V mini PCI slots — PCI Express – Two mini PCI Express Connectors, or – One mini PCI Express connector and one PCI Express x1 connector —...

  • Page 9: Mpc837Xe-Rds Board

    MPC837xE-RDS Board Figure 1 shows the MPC837xE-RDS board block diagram. 48V PoE 48V AC/DC Card LM5072 3.3V DDR2 (x64) EEPROM JTAG/COP Nor Flash (x 16) DDR2 DUART e 300 Core Interrupt Dual I Security Local Bus 32 KB 32 KB Timers Controller Controller...

  • Page 10: Board-Level Functions

    MPC837xE-RDS Board Board-Level Functions The board-level functions discussed in this section are reset, interrupts, clock distribution, and interface specification. 2.1.1 Reset and Reset Configurations The MPC837xE-RDS reset module generates a single reset to reset the MPC837xE and other peripherals on the board. The reset unit provides power-on reset, hard reset, and soft reset signals in compliance with the MPC837xE hardware specification.

  • Page 11: External Interrupts

    MPC837xE-RDS Board • The COP/JTAG port also generates the soft reset for the system. Assertion of SRESET causes the MPC837xE to abort all current internal and external transactions and set most registers to their default values. 2.1.2 External Interrupts Figure 3 shows the external interrupt circuitry to the MPC837xE.

  • Page 12: Clock Distribution

    MPC837xE-RDS Board 2.1.3 Clock Distribution Figure 4 Table 1 show the clock distribution on the MPC837xE-RDS board. 66.666 MHz CLKIN 33/66 MHz Mini PCI Slot 33/66 MHz OCCR Mini PCI Slot PCI_SYNC_OUT M66EN CFG_CLKIN_DIV System PCI_SYNC_IN 50 MHz to 133 MHz local bus LCLKx Local Bus CLK...

  • Page 13: Ddr2 Sdram Controller

    MPC837xE-RDS Board Table 1. Clock Distribution Clock Frequency Module Generated by Description 66.666 MHz MPC837xE CLKIN 66.666 MHz oscillator The MPC837xE uses CLKIN to generate the PCI_SYNC_OUT clock signal, which is fed back to the internal system PLL through the PCI_SYNC_IN signal.

  • Page 14: Local Bus Controller

    MPC837xE-RDS Board MPC837xE DQ[0:63] DQ[0:15] DQ[16:31] DM[0:7] DM[0,1] DM[2,3] DQS[0:7] DQS[0,1] DQS[2,3] DDR2 DDR2 Vref Vref SDRAM SDRAM A[0:12], BA[0:2],CTRL 1Gb(X16) 1Gb(X16) MCK0 MCK1 pair pair DDR2 SDRAM DQ[48:63] DQ[32:47] Controller DDR2 Vref DDR2 Vref DM[4,5] DM[6,7] MSYNC_OUT SDRAM SDRAM DQS[6,7] DQS[4,5] 1Gb(X16)

  • Page 15: Flash Memory

    MPC837xE-RDS Board Figure 6 shows the block diagram and connections for the local bus. MPC837xE Local Bus Controller LCS0 LCS0 LAD[6:26] NOR Flash (16-bit) LAD[0:31] A[6:30] Address A[24:0] BADDR[27:30] Latch LALE LAD[0:15] D[0:15] D[15:0] LCS0 Control Control Signals Control S29GL512N Figure 6.

  • Page 16: Sata Controller

    MPC837xE-RDS Board 2.1.8 SATA Controller MPC837xE has a SATA controller for storage applications as shown in Figure 7. There are two SATA channels for MPC8377E. It requires a 100-MHz input clock, which is provided by the clock generator. 2.1.9 PCI Express Interface (PCI-E & Mini PCI-E) MPC8377E supports the PCI Express (PCI-E) interface.

  • Page 17: Rs-232 Port

    MPC837xE-RDS Board the RTL8211B. Figure 8 shows the connection between the MPC837xE eTSEC1 and eTSEC2 to the RTL8211B. MPC837xE PHY addr = 0x02 RTL8211B eTSEC1 RGMII interface EC_MDIO MDIO RJ-45 EC_MDC (Enet0, supports PoE) 3.3 V LVDD1 eTSEC2 PHY addr = 0x03 RTL8211B RGMII interface 3.3 V...

  • Page 18: Pci Subsystem

    MPC837xE-RDS Board USB3300 PHY connects to a Type A receptacle connector that serves as a host interface. Figure 10 shows the connection of USB. MPC837xE USB3300 ULPI_D[7:0] D[7:0] VBUS ULPI_DIR USB_TYPE_A_RECEPTACLE ULPI_STP ULPI_NXT CLKOUT ULPI_CLK Figure 10. USB Port Connections 2.1.13 PCI Subsystem The MPC837xE has PCI interfaces.
  • Page 19 MPC837xE-RDS Board Ethernet port, USB port, parallel port, RS-232, etc. Figure 12 shows a typical setup using a USB port emulator. Emulator MPC837xE-RDS Figure 12. Connecting the MPC837xE-RDS Board to a Parallel Emulator The 16-pin generic header connector carries the COP/JTAG signals and the additional signals for system debugging.

  • Page 20: Mpc837Xe-Rds Assembly

    MPC837xE-RDS Board MPC837xE-RDS Assembly Figure 14 shows the MPC837xE-RDS board top view, with the references of LEDs, jumpers, headers, and switches. COP Connector Pin 1 48 V DC Power P1 WAN (supports PoE) MPC837xE Mini PCI-E P2 LAN eSATA Mini PCI (Top) Mini PCI (Bottom) Mini PCI-E Reset...
  • Page 21 MPC837xE-RDS Board Figure 15 shows the MPC837xE-RDS board bottom view. SD Socket Figure 15. MPC837xE-RDS Bottom View Table 2 shows references and descriptions of LEDs, jumpers, headers, and switches. Table 2. Lists of Connectors, Jumpers, Switches, and LEDs Reference Description Connectors 16-pin COP/JTAG connector MPC837xE-RDS, Rev.

  • Page 22: Connectors

    MPC837xE-RDS Board Table 2. Lists of Connectors, Jumpers, Switches, and LEDs (continued) Reference Description P3, P4 32-bit 3.3 V mini PCI connector slots. The board supports up to 2 mini PCI devices. USB Type A receptacle (for USB high-speed external device) 48 V DC power jack (external power adapter input) Double-eSATA port COM1 serial port terminal connector (RS-232C) for MPC837xE...

  • Page 23: Rs-232C Connectors

    MPC837xE-RDS Board Table 3. COP Connector Pin Assignments Signal Signal SRESET HRESET CHKSTOP_OUT 2.3.2 RS-232C Connectors Serial interface COM1 is available at connector (J6) with pin assignments as shown in Table Table 4. COM1 Connector Pins Signal 2.3.3 Serial ATA (SATA) Connector The Double-eSATA connector (J16) connects to the serial ATA hard disks through eSATA cables.

  • Page 24: Power Connector

    MPC837xE-RDS Board 2. Press downward Figure 16. Installation of a Mini PCI Card 2.3.5 Power Connector J13 is a DC jack for a 48 V power supply to the MPC837xE-RDS board. LEDs Figure 17 shows 9 LED indicators on the front panel of MPC837xE-RDS. POWER WiFi DIAG...

  • Page 25: Ethernet Leds

    MPC837xE-RDS Board 2.4.3 Ethernet LEDs Green Link1000 LEDs (D9): indicate the link speed is 1000M on WAN and LAN. (The top LED for LAN and the bottom one for WAN) Green Link100 LEDs (D8): indicate the link speed is 100M on WAN and LAN. (The top LED for LAN and the bottom one for WAN) Green Link10 LEDs (D7): indicate the link speed is 10M on WAN and LAN.

  • Page 26: Mpc837Xe-Rds, Rev

    MPC837xE-RDS Board 2.5.3 Reset Configuration Word The reset configuration word (RCW) controls the clock ratios and other basic device functions, such as PCI host or agent mode, boot location, TSEC modes, and endian mode. The reset configuration word is divided into reset configuration word lower (RCWL) and reset configuration word higher (RCWH) and is loaded from the local bus during the power-on or hard reset flow.
  • Page 27 MPC837xE-RDS Board Table 6. RCWL Bit Descriptions (continued) Bits Name Meaning Description 2–3 — Reserved Should be cleared. 4–7 SPMF[0–3] System PLL 0000 16:1 multiplication factor 0001 Reserved 0010 0011 0100 (default) 0101 4–7 SPMF[0–3] System PLL 0110 multiplication factor 0111 1000 1001...
  • Page 28 MPC837xE-RDS Board Table 6. RCWL Bit Descriptions (continued) Bits Name Meaning Description 9–15 COREPLL 01 0010 0 [0–6] 10 0010 0 11 0010 0 00 0010 1 2.5:1 01 0010 1 2.5:1 10 0010 1 2.5:1 11 0010 1 2.5:1 00 0011 0 01 0011 0 10 0011 0...
  • Page 29 MPC837xE-RDS Board Table 7. Reset Configuration Word High (RCWH) Bit Descriptions (continued) Bits Name Meaning Detailed Description 9–11 ROMLOC Boot ROM interface DDR SDRAM location PCI1 Reserved On-chip Boot ROM Reserved Local bus GPCM, 8 bits 110: Default Local bus GPCM, 16 bits Local bus GPCM, 32 bits 12–13 RLEXT...

  • Page 30: Power Supply

    MPC837xE-RDS Board Table 7. Reset Configuration Word High (RCWH) Bit Descriptions (continued) Bits Name Meaning Detailed Description LDP/CKSTP pin LDP[0:3] = local data parity. mux state after reset 1: Default LDP[0:3] = LCS[4:7] Reserved — Should be cleared 2.5.4 Power Supply The MPC837xE requires a 48 V power supply from the DC power jack or PoE for normal operation.
  • Page 31 MPC837xE-RDS Board Table 9. MPC837xE-RDS Board Specifications (continued) Characteristics Specifications Addressing: Total address range 4 Gbyte (32 address lines) Flash memory (local bus) 64 Mbyte NOR Flash DDR SDRAM 512 Mbyte DDR2 SDRAM at DDR400 Operating temperature C to 70 C (room temperature) Storage temperature –25...

  • Page 32: Mechanical Data

    Board Bootup Mechanical Data shows the MPC837xE-RDS dimensions (in mil). The board dimensions are 170 mm × 170 mm Figure 21 (6693 mils × 6693 mils) for integration in a mini ITX chassis with a small footprint. mounting hole 2060.00 2590.00 typ 4 1360.00...

  • Page 33: Board Jumper Settings

    Board Bootup CAUTION Avoid touching areas of circuitry and connectors; static discharge can damage circuits. Board Jumper Settings Figure 22 shows a partial top view of the MPC837xE-RDS with red outlines at jumper designators J7, J10, and J12. A square pad indicates pin 1 of the part. Table 10 shows the default jumper settings.

  • Page 34: External Connections

    MPC837xE-RDS Software External Connections Figure 23shows the external connections. SD Card 48V Power eSATA Reset (Support PoE) Figure 23. External Connections NOTE Strong electromagnetic interference might disturb the normal function of the product. If so, simply reset the product to resume normal operation by following the steps in the software user guide.
  • Page 35 MPC837xE-RDS Software • PPPoE • IGMP • UPnP • SNMP • Wireless Security: • Pre-Shared Key (PSK) • Wi-Fi Protected Access 2 (WPA2) • 802.11i AES-CCMP • Wired Equivalent Privacy (WEP), 128/256-bit • 802.11i EAP authentication with RADIUS Network Security: •...

  • Page 36: Application Connections

    MPC837xE-RDS Software Application Connections Figure 24 shows application connections for MPC837xE-RDS board. Figure 24. MPC837xE-RDS Application Connections Configure the MPC837xE-RDS board by using a web browser. Connect your PC to the LAN port of the board (either directly or through a hub), then use a web browser to configure. TCP/IP settings must be correct.

  • Page 37: Unit Assembly

    Unit Assembly Unit Assembly The assembled unit is composed of the board assembly, an enclosure, screws, and other parts. The instructions in this section apply if you need to assemble or reassemble the product or add peripherals mentioned. Assembling the Enclosure and Board Assembly Assembling the board into the enclosure requires screwing the board onto the base, then screwing the top and base together.
  • Page 38 Unit Assembly 5. Re-assemble using Steps through Section 5.1, Assembling the Enclosure and Board Assembly. MPC837xE-RDS, Rev. 1.0 Freescale Semiconductor Preliminary, Subject to Change without Notice...
