B-Tech BT7004 Installation Manual

Bolt down digital signage mount with screen enclosure

Download this manual

BT7004

bolt down Digital Signage mount

WITH SCREEN ENCLOSURE

INSTALLATION GUIDE

SPECIFICATIONS

• Max load: 50kg (110lbs)

• Suitable for screens with VESA

• Base dimensions: W: 240mm D: 240mm

• Vented top and bottom panels allow airflow to

and from the device

• Integrated cable management

• Simple 'hook-on' screen installation with all mounting

hardware included

and non-VESA fixings

www.btechavmounts.com

Page 1 BT7004 bolt down Digital Signage mount WITH SCREEN ENCLOSURE INSTALLATION GUIDE SPECIFICATIONS • Max load: 50kg (110lbs) • Suitable for screens with VESA ® and non-VESA fixings • Base dimensions: W: 240mm D: 240mm • Vented top and bottom panels allow airflow to and from the device •...
Page 4 BT7004 PARTS LIST Note: Components supplied may differ from what is shown depending on the type and size of the display being installed. PLEASE KEEP THIS FOR FUTURE REFERENCE...
Page 7 ATTACH MOUNTING BRACKET TO RAIL i. Insert 4 x item C2 into item E1 (2 in the top channel, 2 in the bottom channel). ii. Fix item C1 centrally to item E1 using item C3. FIX RAIL TO COLUMN i. Insert 4 x item D1 into item B1 (2 in each channel). ii.
Page 9 FIX SCREEN ENCLOSURE i. Insert 8 x item G5 into item E1 (4 in the top channel, 4 in the bottom channel) and position as shown in fig. 1. ii. Attached item E2 to the ends of item E1. fig.1 110mm 110mm 110mm...
Page 11: Side View
FRONT VIEW REAR VIEW TOP VIEW BASE PLATE 240mm 72mm 165mm 30mm 4 x 10.5mm 86mm 40mm THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
Page 12 ©2021 B-Tech AV Mounts. All rights reserved. B-Tech AV Mounts is a division of B-Tech International Design and Manufacturing Ltd. B-Tech AV Mounts and the B-Tech logo are registered trade marks. All other brands and product names are trademarks of their respective owners.
