- Page 8 FIX INTERFACE ARMS TO SCREEN Fix items 7 to the back of the screen using the interface kit (items A-N). Note: Ensure items 7 are positioned the correct way round. Spacers (items J-M) are to be used for screens with recessed fixings.
-
Page 9: Screen Adjustment
SCREEN ADJUSTMENT Level screen with the height adjustment screws at the top HEIGHT of item 7. ADJUSTMENT SCREW LEVEL SCREEN Note: If necessary, laterally adjust screen by hand. LOCK SCREEN TO MOUNTING PLATE (OPTIONAL) Secure screen onto item 6 using the locking screws at the bottom of item 7.
