BT8709
PREMIUM FREESTANDING
SINGLE SCREEN TWIN COLUMN
UC STAND
INSTALLATION GUIDE
SPECIFICATIONS
• Recommended for screens up to: 100" (254cm)
• Max load: 100kg (220lbs)
• Suitable for displays with fixings up to 972 x 800mm
• Stand dimensions: H.1945 x W.1128 x D.757mm
• Integrated cable management
www.btechavmounts.com
Advertisement
Table of Contents
Related Manuals for B-Tech BT8709
Summary of Contents for B-Tech BT8709
- Page 1 BT8709 PREMIUM FREESTANDING SINGLE SCREEN TWIN COLUMN UC STAND INSTALLATION GUIDE SPECIFICATIONS • Recommended for screens up to: 100" (254cm) • Max load: 100kg (220lbs) • Suitable for displays with fixings up to 972 x 800mm • Stand dimensions: H.1945 x W.1128 x D.757mm •...
-
Page 2: Installation Safety Instructions
Please check carefully to make sure there are no missing or defective parts - defective parts must never be used. B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire. -
Page 4: Installation Tools Required
BT8709 PARTS LIST PLEASE KEEP THIS FOR FUTURE REFERENCE INSTALLATION TOOLS REQUIRED Crosshead screwdriver Pliers/Cutter... -
Page 5: Mounting Rail
ITEM PART DESCRIPTION 1.9M COLUMN END CAP COLUMN REAR COVER M6 x 12mm HEX SCREW M6 x 12mm GRUB SCREW (OPTIONAL) SQUARE NUT (OPTIONAL) COVER STRIP 3AF HEX KEY 4AF HEX KEY BASE - LEFT SIDE BASE - RIGHT SIDE BASE CONNECTOR ADJUSTABLE LEVELLING FEET M6 x 30mm CSK HEX SCREW... - Page 6 Installation Instructions ASSEMBLE BASE i. Fix item B1 to item B2 using items B3 & B6 on the front and back. M10 x 25mm HEX SCREW ii. Screw item B4 into items B1 & B2. OPTIONAL - FIX REAR COVERS TO COLUMNS Place item A2 into the back of item A1.
- Page 7 OPTIONAL: To level the stand, ATTACH COLUMNS TO BASE adjust item B4 using item B9. Mount items A1 onto items B1 & B2 and fix in place using item B5. M6 x 30mm CSK HEX SCREW ATTACH MOUNTING BRACKETS TO COLUMNS i.
- Page 8 HOOK RAILS ONTO MOUNTING BRACKETS i. Insert 4 x item C4 into item D1 (2 in the top channel, 2 in the bottom channel) on each side of the rails. M8 SLIDING M8 x 12mm ii. Screw 2 x item C5 into item C4 in the top channel - allow at least a 6mm gap HEX SCREW INSERT so the rail can be hooked on to item C1.
- Page 9 FIX END CAP TO COLUMNS Fix item A2 onto the top of items A1 using item A4. M6 x 12mm HEX SCREW ATTACH INTERFACE ARMS TO SCREEN Fix items E1 to the rear of the screen using items E3 - E16. Note: Ensure the arms are facing the correct way round and the same holes are used on both arms.
- Page 10 LOCK SCREEN TO RAIL HOOK SCREEN ONTO RAIL Tighten the safety screws on the bottom Use items E1 to hook the screen of item E1 securing the screen to item D1. onto item D1. Note: If necessary, adjust the height adjustment screws on top of item E1 to level the screen.
-
Page 11: Front View
BT8709 DIMENSIONS PLEASE KEEP THIS FOR FUTURE REFERENCE FRONT VIEW SIDE VIEW 141.5mm 326mm 79.5mm 180mm 60.8mm 24mm TOP VIEW BOTTOM VIEW 1127.7mm 1029.1mm 1005mm 70mm 40mm 506mm 973mm 1078.5mm These instructions are intended as a guide only and B-tTech accepts no liability for the accuracy of the information contained in this document. - Page 12 ©2020 B-Tech AV Mounts. All rights reserved. B-Tech AV Mounts is a division of B-Tech International Design and Manufacturing Ltd. B-Tech AV Mounts and the B-Tech logo are registered trade marks. All other brands and product names are trademarks of their respective owners.
