Altronix TROVE T2MK3F4D Installation Manual page 4

T2MK7F8D, T2MK7F8Q: Configuration of Mercury Boards:
1. Fasten snap on spacers onto metal pems configuration (A), (B), (C) or (D) of backplane depending on the access controller (Fig. 3, pg. 4).
2. Position access controller module over corresponding spacers and depress onto snap on spacers (Fig. 3a, pg. 4).
3. Mount backplane to enclosure with hardware.
Access Controller Position Chart for the Following Models:
Mercury Access Controller
EP1502, MR52, MR16IN, MR16OUT
EP2500, MUX8
EP1501, MR51e
MR50
Fig. 3
Altronix - eFlow104NB
L G N
IN GND IN GND IN GND IN GND IN GND IN GND IN GND IN GND
5 6
1 2 3 4
F1 F2 F3 F4 F5
Altronix - ACM8CB
NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM
OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4
Altronix PDS8CB
Altronix VR6 is mounted under PDS8CB
- 4 -
Altronix LINQ2 Module (T2MK7F8DQ)
FACP
TRIGGER
TRG
INPUT
7 8
F6 F7 F8
O N O N O N O N
1 1 2 2 3 3 4 4 1 1 2 2 3 3 4 4
MAIN
10A 250V
OUTPUT 5 OUTPUT 6 OUTPUT 7 OUTPUT 8
B A
C C
B
C C
B
C
D D
B
A
A
A
Trove2/Mercury PTC Kits Installation Guide
Pem Mounting
A
B
C
D
Fig. 3a
Pem
Snap On
Spacer
Backplane
Mercury Board
