Access & Power Integration
Altronix/AMAG M4000 Kits
Models Include:
T2AGK78
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AGK78S
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AGK712
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) ACM4 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AGK712S
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) ACM4 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Modulee
T2AGK7512
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) AL1012ULXB - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) ACM4 - Fused Access Power Controller
- One (1) PD4UL - Fused Power Distribution Module
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TAGLK_121924
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2AGK78D
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AGK78SD
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AGK712D
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) ACM4CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AGK712SD
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) ACM4CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Modulee
T2AGK7512D
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) AL1012ULXB - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) ACM4CB - PTC Access Power Controller
- One (1) PD4ULCB - PTC Power Distribution Module
More than just power.™
