- Page 1 AsteRx4 Product Family Hardware Manual Version 1.5.0...
- Page 2 AsteRx4 Product Family Hardware Manual Version 1.5.0 March 27, 2017 © Copyright 2000-2017 Septentrio nv/sa. All rights reserved. Septentrio Satellite Navigation Greenhill Campus, Interleuvenlaan 15i 3001 Leuven, Belgium http://www.septentrio.com support@septentrio.com Phone: +32 16 300 800 Fax: +32 16 221 640...
-
Page 3: Table Of Contents
2.12 Applicable Firmware Package ................17 2.13 Hardware Specifications ..................17 2.13.1 Power Management ....................17 2.13.2 Temperature Range ....................17 ASTERX4 EVALUATION KIT ..................18 Interface Board Overview ..................18 Headers and Jumpers.................... 19 Push-Buttons ......................21 Connectors ......................21 3.4.1 80-pin Connector ...................... - Page 4 SD-Card Socket ....................... 23 APPENDIX A LED STATUS INDICATORS ................. 24 APPENDIX B MEASURING THE ASTERX4 POWER CONSUMPTION ......26...
- Page 5 2002/95/EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive). Receivers of the AsteRx4 family comply with the European Union (EU) Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). The purpose of...
- Page 6 Statement 0001/WARNING: The power supply provided by Septentrio (if any) should not be replaced by another. If you are using the receiver with your own power supply, it must have a double isolated construction and must match the specifications of the provided power supply.
- Page 7 Electronic components and assemblies, such as Septentrio OEM receivers, can be permanently damaged or destroyed when near or in contact with electro-statically charged objects. When you handle components or assemblies that are not in protective bags and you are not sure whether they are static-sensitive, assume that they are static-sensitive and handle them accordingly.
-
Page 8: Asterx4_Oem
AsteRx4_OEM 2 AsteRx4_OEM Main 2.1 Mechanical Drawings Weight: 68g Height: Bottom-side components: o 80-pin connector: 4.57mm o MMCX connector: 3.70mm Top-side shield height: max 3.40mm All mounting holes have an inner diameter of 3.2mm (intended for M3 screws). - Page 9 AsteRx4_OEM Main The break-off tabs are shown in yellow below:...
-
Page 10: Antenna Connectors
AsteRx4_OEM 2.2 Antenna Connectors Type: MMCX, right angle DC voltage: As provided by pin#14 of the 80-pin connector Gain range: 15 dB to 50 dB (antenna gain minus cable losses) The right-angle MMCX connectors are mounted on the bottom side of the board and protrude 1.2mm beyond the edge of the PCB. - Page 11 AsteRx4_OEM Sleep/off mode can be detected by the fact that the voltage at pin#29 (VCC_3V3_OUT) is zero. Pin#29 can be used as an “enable” for the drivers driving the input pins. When pull-up resistors are needed, 10k is recommended. Always pull-up to 3.3V even when using another voltage at the Vin pins.
- Page 12 AsteRx4_OEM Pin# Name Type Level Description Connection Tips Ground. All ground pins must be connected. USB_D- USB data signal negative D-. Leave unconnected if USB not used. See also section 2.8. USB_D+ USB data signal positive D+. Leave unconnected if USB not used. See also section 2.8.
- Page 13 AsteRx4_OEM Pin# Name Type Level Description Connection Tips Ground. All ground pins must be connected. USB_Vbus 4.35V USB Power. Cannot be used to power the receiver. Leave unconnected if USB not used. ≤V ≤ high 5.25V Ground. All ground pins must be connected. nPWR_ LVTTL Power toggling input, active negative.
-
Page 14: Frequency Reference Selection
AsteRx4_OEM 2.4 Frequency Reference Selection The receiver can get its 10-MHz frequency reference from its internal TCXO, or from an external reference source. The clock selection is controlled by the EXTREF_STAT pin (pin#55), as follows: EXTREF_STAT pin level Reference clock Signal at REF_O pin (pin#39) source Pin left open (there is... -
Page 15: Usb Device
AsteRx4_OEM USB Device The user can configure the USB bus (pins#3 and #5) in either USB 1.1 (full speed) mode, or in USB 2.0 (high speed) mode. USB 2.0 allows higher bandwidth, but may not be supported by all host hardware. By default, the USB bus is configured in USB 1.1 mode. -
Page 16: Sd Memory Card Usage
AsteRx4_OEM After having requested to enter stand-by mode, it takes up to 0.5 seconds for the receiver to actually enter low-power state. This time is required to unmount the SD memory card (if applicable) and to stop all software activities. Waking up from stand-by mode is done in one of the following ways: 1. -
Page 17: Applicable Firmware Package
When Ethernet is enabled and the LAN link is active, add 560 to 700 mW to the values in the table. Stand-by mode: 17 mW A method to measure the power consumption using the AsteRx4 Evaluation Kit is explained in Appendix B. 2.13.2 Temperature Range Operational: -40 to +85 °C... -
Page 18: Asterx4 Evaluation Kit
AsteRx4 Evaluation Kit 3 AsteRx4 Evaluation Kit 3.1 Interface Board Overview 80-pin connector to the AsteRx4_OEM VCC_IN Serial Ethernet ports Events and PPS Length 230 mm Width 100 mm Total height 40mm... -
Page 19: Headers And Jumpers
AsteRx4 Evaluation Kit 3.2 Headers and Jumpers S1-S4 V_MAIN SELECT VCC_ANT SELECT The interface board is configured through six headers/jumpers: S1, S2, S3, S4, V_MAIN SELECT and VCC_ANT SELECT. The default jumper configuration is as follows: Header Name Default Jumper Config... - Page 20 AsteRx4 Evaluation Kit...
-
Page 21: Push-Buttons
AsteRx4 Evaluation Kit 3.3 Push-Buttons Button name Function Details PWR_TOGGLE Press this button to toggle When pressed, the nPWR_TOGGLE pin of the between active and stand-by AsteRx4_OEM receiver (pin#8) is driven low. mode. When released, the nPWR_TOGGLE pin is left open. -
Page 22: Serial Connectors
AsteRx4 Evaluation Kit Name printed Pin of the 80-pin connector Function on the board REF_PIO Pin#39 These pins are tied together in the interface board. The signal on these pins REF_I_PIO Pin#43 is the 10-MHz frequency reference. EVENT_A Pin#34 First event marker (input) -
Page 23: Antenna Connector
AsteRx4 Evaluation Kit 3.4.7 Antenna Connector The interface board has no antenna connector, the antenna has to be connected directly to the main or aux MMCX connector of the AsteRx4_OEM board. When the jumpers are set in their default configuration as defined in section 3.2, a 3.3V- DC voltage is available at the antenna connector. - Page 24 Appendix A LED Status Indicators Appendix A LED Status Indicators A.1 AsteRx4_OEM LEDs The LED pins of the 80-pin connector (see section 2.3) can be used to monitor the receiver status. They can be used to drive external LEDs (max drive current 8mA). It is assumed that the LED lights when the electrical level of the corresponding pin is high.
- Page 25 Appendix A LED Status Indicators A.2 Interface Board LEDs The 28 red LEDs on the interface board report the current state of selected pins of the 80- pin connector. A LED lights when the electrical level at the corresponding pin is high. The following table indicates which pin of the 80-pin connector corresponds to each of the LEDs.
- Page 26 Appendix B Measuring the AsteRx4 Power Consumption Appendix B Measuring the AsteRx4 Power Consumption The following procedure can be used to measure the power consumption of the AsteRx4_OEM receiver board separately from the power consumption of the interface board: remove the S1 jumper;...
