Okamura Portone Quick Start Manual

/
Assembly Instruction & Instructions for Use
Component List
■ Main body (standard parts)
Gas lift × 1 pce.
Base × 1 pce.
Castor×5 pcs. 1pack
Hexagon socket bolt
(M8×22L) × 3 pcs. (Portone)
Hexagon socket bolt
(M8×22L) ×4 pcs. (Portone Smart)
Safety Instructions ( Make sure to follow these instructions )
Indicates that improper handling may cause injury or
Caution
property damage.
・Do not handle roughly, or use improperly.
・ Do not use as a carrier.
・ Do not stand on the chair or sit on
the front side of seat or armrest.
・ Do not sit on any parts other than
the seat.
・ Do not disassemble or repair on your own. Please contact official
dealers when needed.
・ No remodeling. Okamura will have no responsibility for any disadvantage
caused by remodeling.
・ Gas lift replacement and handing should only be carried out by the
trained professional.
・Be careful not to get your fingers,
hands or clothes caught in the
gaps between the moving parts
or the back of the pad when
adjusting the position of the arm.
Also, make sure that the arm are
second tightly become use.
■ Option parts
Backrest × 1 pce.
Seat × 1 pce.
( Check the components before starting assembly )
Adjustable arm × 1 pce. each
(Right)
Hexagon socket bolt
(Left) ( M6 × 45L ) × 6 pcs. (Steel)
(M6×50L) ×6 pcs. (Aluminum)
Hexagon socket bolt
(M6×32L) × 2 pcs.
Headrest × 1 pce.
Hexagon nut (M6) × 2 pcs.
Instructions to Extend the Life of Product Instructions to Extend the Life of Product
Please follow instructions below. Failure may cause serious damage to
the product.
・Indoor use only.
・No outdoor or waterfront use.
・Avoid direct sunlight.
・W h e n p l a c i n g a l o n g s i d e
windows, use curtain or blind to
aavoid from direct sunlight.
Nominated
Tools
Hex key wrench
( 5 mm )
・Avoid high temperature, high
humidity, or extraordinary aridity.
・Do not place product under
h e a t e r o r a i r- c o n d i t i o n e r
exhausting high temperature air.
・Do not place on uneven floor.
