O f f i c e
S e a t i n g
I n s t r u c t i o n s f o r U s e
OKAMURA CORPORATION
INTERNATIONAL SALES & MARKETING DIVISION
2-14-27, Akasaka, Minato-ku, Tokyo 107-0052, JAPAN
Tel : +81-3-5561-4085
Fax : +81-3-5561-4086
G98756
//
.
/
http:
www
okamura.jp
2014-12
Advertisement
Related Manuals for Okamura Sabrina
Summary of Contents for Okamura Sabrina
- Page 1 O f f i c e S e a t i n g I n s t r u c t i o n s f o r U s e OKAMURA CORPORATION INTERNATIONAL SALES & MARKETING DIVISION 2-14-27, Akasaka, Minato-ku, Tokyo 107-0052, JAPAN...
- Page 2 Black Please contact our official dealers when needed. Soft caster Hard caster No remodeling. Okamura will have no Be careful not to get responsibility for any disadvantage caused by your fingers, hand or remodeling. clothes caught in the gaps between the...
-
Page 3: Installation
Installation For maintenance Regular maintenance is tips for long-life use. For mesh and cushion Please follow instructions below. Failure may cause serious damage to the product. parts, remove dust by If found unstable due to loose bolts and tapping the cloth surface screws, tighten them. - Page 4 Part names Adjustable range 10° 23° Backrest Headrest (option) Hanger (option) 60mm Fixed arm (option) Seat (2 3/8”) Arm height Seat slide lever 100mm adjustment button (4”) Lumbar support (option) Seat height adjustment lever Reclining lock/ Adjustable arm release dial (option) Backrest frame 50mm...
- Page 5 Operation guide Seat height adjustment Seat depth adjustment Adjust the seat height using the seat height adjustment Adjust the seat depth by sliding the seat forward or lever on the bottom right of the seat. The seat will be back within a range of 50 mm (2”) using the Seat lowered if you lift the lever while seated, and it will stop slide lever on the bottom left of the seat.
- Page 6 Operation guide Reclining adjustment Dial position to lock and release the backrest recline Before adjusting the backrest recline, release the Turn the reclining lock/release dial to the (A), (B), or (C) position to lock and release the backrest recline. lock by using the reclining lock/release dial on the bottom left of the seat.
- Page 7 Operation guide Backrest recline from the FRONT position to the NORMAL position Backrest recline to the BACK position (1) Turn the dial to (A) to release the lock. The backrest recline can be adjusted within a range of 23°. (2) Lean against the back to move the backrest recline backward, and turn the dial clockwise once to the (B) (1) Turn the dial to (B) to release the lock.
- Page 8 Operation guide Reclining tension adjustment Adjustable arm (option) height adjustment Adjust the reclining tension by using the reclining Release the height lock using the arm height tension adjustment dial on the bottom right of the adjustment button on the bottom of the arm pad. seat.
- Page 9 Operation guide Part attachment and replacement Lumbar support (option) height adjustment Headrest (option) attachment and replacement Move the Lumbar support on the back side of the backrest, up and down directly. The Lumbar (1) Insert the grooves of the Headrest into the backside of the support can be moved up and down within a range backrest.
-
Page 10: Troubleshooting
Materials Troubleshooting Part Materials Problem Check Solution Page Body Glass-reinforced polyamide >PA-GF< Are you sitting on the seat Adjust the seat height while Backrest when adjusting the seat Frame Metal (aluminum) >ADC< not seated on the seat. height? The seat cannot be lifted up. Shell Polypropylene >PP<...
