Components - Scilogex SCI100VC Operating Instructions Manual

Steam temperature
External
WxDxH
Weight
Input power supply
Working temperature
Input power
Maximum output power

2.3 Components

Touch screen
Name
Touch screen
Three-in-one
switch
Communication
interface
Pump interface
5℃-40℃
dimension
189mm×207mm×193mm
4.0kg
AC110—240V, 50Hz/60Hz
10℃-40℃, ≤80%RH
600W
500W (220V), 300W(110V)
Fig. 2.3.1
Description
Setting parameters and displaying settings and
operation information
Unit power input, with a switch controlling the
power supply to the entire unit.
Communication
Connects the vacuum pump
Three-in-one switch
Communication
interface
Pump interface
Air vent
Load interface
3
Power output
socket
Fig. 2.3.2
